Hiltron Evac VVFF microphone stand 12 buttons 24 VDC with display EVAC12C
C1A EVAC12C
Hiltron microphone stand with touch screen display for voice evacuation, a professional emergency management device designed for voice evacuation systems. Equipped with a touch screen display, it allows you to manage up to 12 zones, send alert and evacuation messages, and monitor the status of the system by means of signaling LEDs, with the following features:
-
Audio power: 500 W total, max 250 W per zone
-
Display: 4.3-inch backlit touch screen
-
Zones: Management of up to 12 zones
-
Power supply: 24 VDC
-
Functions: Hands-free messaging, pre-recorded, broadcast calls, AUX function
-
Monitoring: LED status indicators and faults
€639.80
Items Available: 2
Frequently bought together
Hiltron Evac VVFF microphone stand 12 buttons 24 Vdc with display
The EVAC12C microphone stand enables live or pre-recorded emergency messages for alerting and evacuation, ensuring maximum efficiency in a crisis. With intuitive controls, you can quickly select affected zones and monitor system status through the display and indicator LEDs.
Zone selection and AUX functionality
With up to 12 manageable zones, the device allows customized or pre-configured messages to be sent to specific zone combinations via the AUX feature. Ideal for large public buildings, schools, hospitals and shopping malls, it offers precise and flexible management of emergency communications.
Intuitive interface and connectivity
The 4.3-inch backlit touch screen display allows smooth navigation between configuration options, volume levels and zone selection. The console has dedicated buttons for pre-recorded messages, broadcast calls, and fault management, making operations simple and efficient.
Installation and compatibility
The EVAC12C microphone stand is designed to be wall-mounted and is compatible with additional microphones for a complete configuration. The system is powered via a 24 VDC connection and supports inputs and outputs for easy integration with fire alarm systems.
Technical Features.
| Feature | Detail |
|---|---|
| Supply voltage | 24 Vdc |
| Maximum power consumption 24Vdc | 130 mA |
| Typical output level | 300 mV |
| Distortion | < 1% |
| Signal to noise ratio | > 60 db |
| Signal to noise ratio (A-weighted) | > 65 db |
| Frequency response | 130 to 19,000 Hz |
| Low Cut Filter | -3 dB / 380 Hz |
| Dimensions | 230x80x200 mm (WxHxD) |
| Weight | 1.55 kg |
There are no reviews
Data sheet
- Type: Microphone stands
