Cabur Easy Power switching power supply 120W 24Vdc IP20 XCSL1120W024VAA
CBR XCSL1120W024VAA
8017963183239
Cabur Easy Power switching power supply, robust and efficient. Adjustable output, full protections, alarm contact and DIN rail mounting. Ideal for switchgear and automation, with the following features:
-
Input voltage: 85-264V AC/100-370V DC
-
Output voltage: 24V DC(adjustable 16-28 Vdc)
-
Rated current: 5A
-
Power: 120 W
-
Short circuit: 15A for 50 ms
-
Input/output isolation: 3 kVac / 60 s
-
Degree of protection: IP20
-
Dimensions: 40x115x115 mm
€48.27
Items Available: 8
: 3
Cabur Easy Power Supply - Safe and Reliable Performance
The Easy Power by Cabur line of power supplies is designed to ensure a stable and protected supply of 24 Vdc, ideal for industrial devices and civil installations.
Wide and Universal Single-phase Input
Thanks to the extended range:
-
AC: 85 to 264 Vac
-
DC: 100 to 370 Vdc
Perfect for installations worldwide, with derating below 130 Vdc.
Compatibility and Expandability
-
Paralleling possible for increased power
-
Redundancy with external ORing diode
-
Dry alarm contact for remote monitoring
Can be used in automation, video surveillance systems, LED lighting, PLCs, building automation and more
Technical Specifications Cabur switching power supply
| Parameter | Value |
|---|---|
| Input voltage | 85-264 Vac / 100-370 Vdc |
| Output voltage | 24 Vdc ±1% (adjustable 16-28 Vdc) |
| Rated current | 5 A |
| Rated power | 120 W |
| Overload | >6.2 A for more than 30 s |
| Short circuit | 15 A for 50 ms |
| Ripple | 50 mVpp |
| Efficiency | 85% |
| Protections | Short circuit, overvoltage, overload, overtemperature |
| Galvanic isolation | Input/output: 3 kVac - Input/PE: 1.5 kVac - Output/PE: 0.5 kVac |
| Alarm contact | Max 1 A @ 24 Vdc (Uout > 22V) |
| Status LEDs | DC OK |
| Mounting | Vertical on DIN rail IEC60715 |
| Minimum distance from other components | 20 mm |
| Operating temperature range | -20 to +70 °C (derating > 50 °C) |
| Degree of protection | IP20 |
| Safety standards | EN 62368-1, EN 60950-1 |
| EMC Standards | EN 61000-6-1/2/3/4 |
| Category/grade | Overvoltage II, pollution 2 |
| Material | Aluminum |
| Dimensions (W x H x D) | 40 x 115 x 115 mm |
| Weight | 400 g |
| Terminals | Compatible with cables up to 2.5 mm² |
There are no reviews
Data sheet
- Type: Power supplies
