Fantini Cosmi regulating pressure switch up to 3-7 bar B01C
FAN B01C
8025863000426
The Fantini Cosmi B01C pressure switch is a reliable solution for pressure regulation in plumbing and heating systems, for inert fluids and gases. Built with high-quality materials, it ensures optimal performance and durability, making it ideal for professional and industrial applications. Suitable for steam boilers, dyeing machines, irrigation systems, etc.
€36.86
Items Available: 5
: 3
Fantini Cosmi regulating pressure switch up to 3-7 bar B01C
- Adjustmentrange: Adjustable pressure from 3 to 7 bar for precise control.
- Durable materials:
- Stainless steel fluid contact parts for strength and reliability.
- Shockproof and self-extinguishing V0 thermoplastic base, cover and knob.
- Protection of electrical connections: PVC grommeted outlet for added safety
Wide temperature range:
- Controlled fluid: Maximum temperature of 120°C.
- Pressure switch body: Operating from -35°C to 80°C.
- Storage temperature: -35°C to 80°C
- Compact design: Unit weight of only 0.15 kg for easy installation
Electrical Characteristics
- Rated insulation voltage (Ui ): 380V~.
- Rated continuous service current (Ith): 15A
Key Advantages
- Guaranteed safety: High-quality materials and connection protection for reliable operation.
- Versatility: Ideal for a variety of applications, including heating and plumbing systems.
- Strength and durability: Rugged construction to withstand high temperatures and harsh operating conditions.
- Ease of use: Intuitive adjustment and lightweight design for uncomplicated installation
Technical specifications of the Fantini Cosmi B01C pressure switch
Materials:
- Parts in contact with the fluid: Stainless steel.
- Base, cover and knob: Shockproof and self-extinguishing thermoplastic V0.
- Cable grommet: PVC
Recommended Applications
- Plumbing systems: Pressure control in water circuits
- Heating systems: Regulation and monitoring of hot water pressure
- Industrial applications: Systems requiring reliable pressure control
There are no reviews
Data sheet
- Type: Pressure switches
