Weidmuller Case Closed Base 16P with Cable Hook 2XM25 1788240000
WEI 1788240000
4032248205776
Weidmuller case, with the following features:
- Size: 6
- Cross hook at the bottom
- Standard shape
- Cable entry size: M 25
- Vertical position: 64 mm
- Height (inches): 2.52 inch
- Width: 56.5 mm
- Fixing height: 45 mm
- Fixing width: 105 mm
- Net weight: 357.8 grams
- Temperature limit values: -40/+125 °C
- Tightening torque: 1.2 Nm
- Degree of protection: IP65 (in engaged condition)
- Housing base material: die-cast aluminum
- Clamping element material: Steel, stainless
- Surface: Powder coated
- Color (RAL): RAL 7035
€19.41
Items Available: 25
: 4
There are no reviews
Data sheet
- Type: Cases
