Siemens Simatic S7-1500 8 OUT 16BIT Analog Output Module 6ES75325HF000AB0
SIE 6ES75325HF000AB0
4025515080176
Siemens Simatic S7-1500 AQ8xU/I HS analog output module, 16-bit resolution, 0.3% accuracy, 8 channels in groups of 8, diagnostics; substitute value 8 channels in 0.125 ms Oversampling; unit supports safe disconnection of load groups up to SIL2 according to EN IEC 62021:2021 and category 3 / PL d according to EN ISO 13849-1:2015. delivery including power supply element, screen bracket and screen clamp: front connector (screw terminals or push-in) to be ordered separately.
€1,062.57
Items Available: 6
Features:
- Product type designation AQ 8 x U/I HS
- Hardware version From FS01
- Firmware version V2.1.0
- FW upgrade possible Yes
- Product function I&M data Yes; I&M0 ... I&M3 - operation with clock synchronism Yes
- Engineering with STEP 7 TIA Portal plannable/incorporated from version V14 / - STEP 7 plannable/incorporated from version V5.5 SP3 / - PROFIBUS from version GSD/revision GSD V1.0 / V5.1 PROFINET from version GSD/revision GSD V2.3 / -
- Oversampling operating mode Yes - MSO Yes
- CiR - Configuration in RUN Reparameterization in RUN possible Yes - Calibration in RUN possible Yes
- Supply voltage Nominal value (DC) 24 V - Permissible range, lower limit (DC) 19.2 V - Permissible range, upper limit (DC) 28.8 V - Reverse polarity protection Yes
- Current consumption, max. 320 mA; with 19.2 V power supply
- Power withdrawal from the backplane bus 1.15 W
- Power loss, typ. 7 W
- Analog outputs Number of analog outputs 8 - Voltage output, short-circuit protection Yes - Voltage output, short-circuit current, max. 45 mA - Current output, no-load operating voltage, 20 V
- Dimensions: Width 35 mm - Height 147 mm - Depth 129 mm
- Weight 325 g.
There are no reviews
Data sheet
- Type: Analog Output Modules
- Voltage: 24V
