Vimar Linea View Wireless IoT Smart Multiway switch 30802

Vimar
Vimar
VIW 30802 8007352689596

Electronic mechanism Multiway switch VIEW Wireless:



  • Local push-button or remote control
  • IoT technology on Bluetooth 5.0 standard
  • RGB LED dark detection with intensity adjustment
  • Power supply 100-240 V 50/60 Hz
  • To be completed with interchangeable buttons
  • 1 module



The device has two front buttons that can control the group with which the device has been associated or recall a scenario. It is configured in the Bluetooth technology system through the View Wireless lapp and thanks to the 30807.x-20597-19597-16497-14597 gateway, it interacts with all other devices in the system. It can also recall scenarios created with the View app.



To be applied only to Vimar Linea series frames codes: 30613/30614/30617.

  • bluetooth
    • Offer expires in
    Do you have questions about this product or did you not find what you were looking for? Ask us!
    Vimar Linea View Wireless IoT Smart Multiway switch 30802
    €40.25
    €39.04
    €39.04

    Lowest price in 30 days:
    €40.25
    Save 3%
    €39.04
    Tax included
    Calculate shipping cost
    Offer expires in
    Items Available: 228
    Further availability of the manufacturer
    €39.04

    Buy it within and receive it from Tuesday, 30 December
    Two-year warranty
    Easy return within 14 days
    Purchase with tax breaks

    Are you a professional ?

    Request access to

    Trustpilot

    Frequently bought together

    The front keys can be configured for the following functions:

    • Light group control and miscellaneous: Pressure: ON command (UP key) or OFF command (DOWN key)
    • Light group control with dimmer actuators: Short pressure: ON command (UP key) or OFF command (DOWN key) - Long pressure: load adjustment (UP key = increase; DOWN key = decrease)
    • Roller shutter group command: Long pressure: roller shutter up command (UP key) or roller shutter down command (DOWN key) - Short pressure: movement STOP command (UP or DOWN key indifferently) or slat rotation if the shutter is stopped - Double pressure of any of the two keys: recall of the preferred position (memorization is done through the View Wireless App)
    • Scene recall command: Pressure: scene recall associated with the upper key (UP key) or scene recall associated with the lower key (DOWN key)




    Compatible interchangeable keys: 31000.B - 31000.C - 31000.G - 31000.LB - 31000.LC - 31000.LG - 31000A.B - 31000A.C - 31000A.FB - 31000A.FC - 31000A.FG -31000A.G - 31000A.LG - 31000A.LC - 31000A.LG - 31000A.RB - 31000A.RC - 31000A.RG - 31000A.SB - 31000A.SC - 31000A.SG - 31000S.B - 31000S.C - 31000S.G.



    Features:

    • Rated supply voltage: 100-240 V~, 50/60 Hz
    • Power consumption: 5 mA
    • Transmitted RF power: < 100mW (20 dBm)
    • Frequency range: 2400-2483.5 MHz
    • Terminals: 2 (L and N) for line and neutral
    • 2 front buttons that are used both for control and as configuration buttons
    • RGB LED indicating group status (settable from View Wireless App) and configuration status (flashing blue)
    • Operating temperature: -10 to +40 °C (for indoor)
    • Degree of protection: IP20
    • Configuration from App View Wireless for Bluetooth technology system

    There are no reviews

    Data sheet

    Smart System:
    Smart Multiway Switches
