Vimar Linea IoT Smart Dimmer 220-240V 30805

Vimar
Vimar
VIW 30805 8007352707184

Vimar Linea Smart  dimmer:



  • Electronic VIEW Wireless
  • For incandescent lamps 20-200 W
  • For LED lamps 2-200 W
  • Electronic Transformers 20-200 W
  • Dual IoT technology on Bluetooth 5.0 standard for realizing VIEW Wireless mesh system and on Zigbee 3.0 standard
  • 1 input for external button for dimmer control or scenario recall
  • RGB LED detection in the dark with intensity adjustment
  • 220-240 V 50/60 Hz power supply
  • 1 module



To be completed with interchangeable buttons: 31000A.RB - 31000A.RC - 31000A.RG.



To be applied only to Vimar Linea series frames codes: 30613/30614/30617.

  • bluetooth
    • Do you have questions about this product or did you not find what you were looking for? Ask us!
    Vimar Linea IoT Smart Dimmer 220-240V 30805
    €52.64
    €52.64

    €52.64
    Tax included
    Calculate shipping cost
    Items Available: 54
    Further availability of the manufacturer
    €52.64

    Buy it within and receive it from Tuesday, 24 February
    Two-year warranty
    Easy return within 14 days
    Purchase with tax breaks

    Are you a professional ?

    Request access to

    Trustpilot

    Frequently bought together

    Advantages:

    • Compatible with both LE and TE dimmable lamps
    • Also configurable as a switch while waiting to install a dimmable lamp
    • Bluetooth mode compatible with Amazon Alexa, Google Assistant, Apple Homekit and IFTTT voice assistants, via Vimar's dedicated gateway
    • Zigbee mode compatible with Amazon Alexa assistant, via Amazon Zigbee hub
    • Ability to dim multiple lamps, as long as they are of the same type



    Front buttons on the device control only the on-board dimmer:

    • Short press: turn on (UP button) or turn off (DOWN button) the dimmer
    • Long pressure: load dimming (UP key = increase; DOWN key = decrease)



    IMPORTANT: The lamps controllable by a single dimmer must all be the same. All controlled loads must be declared DIMMERABLE by the manufacturer. Check the lamp packaging for the compatible dimming type: LE (Leading Edge) or TE (Trailing Edge). Where this is not indicated, the lamp can operate in either mode and it is at the installer's discretion to choose the type of dimming that provides the best lamp operation.



    Features:

    • Rated supply voltage: 220-240 V~, 50/60 Hz
    • Transmitted RF power: < 100mW (20 dBm)
    • Frequency range: 2400-2483.5 MHz
    • 2 front buttons that are used both for load control and as configuration buttons
    • RGB LED indicating load status (settable from View Wireless App) and configuration status (flashing blue)
    • In Bluetooth technology mode, the following can be associated with the device: - Up to 16 connected commands (items 30801, 20591.0, 19591.0, 19591, 14591.0, and 14591) - Up to 2 radio commands (items 03925 and 30504) that allow actuator control or scenario activation



    Switching on, switching off and dimming the load by means of:

    • Built-in illuminated pushbuttons (LEDs)
    • Electromechanical pushbuttons in closing not illuminated (pushbutton connection between Neutral and P).
    • Connected electronic controls (items 30801, 20591.0, 19591, 19591, 14591.0 and 14591)
    • Radio controls (items 03925 and 30504)




    Terminals:

    • 2 terminals (L and N) for line and neutral
    • 1 terminal (P) for connection to remote wired control (e.g. art. 30805-20008-19008-14008). The maximum distance between IoT device and pushbutton is 50 m with minimum cable cross-section of 1.5 mm2
    • 1 terminal for regulated output
