Illuminator LNB FTE 8 Independent outputs HQOCTO
FTE HQOCTO
8436545302095
Low Noise FTE Low Noise Converter RED Compilant with two independent outputs, low noise with 0.1 dB figure, allows the reception of satellite signals from a satellite having the full 1st IF band.
€61.91
Items Available: 20
: 10
STRENGTHS
- Complies with the RED Radio Equipment Directive
- Low noise figure and high gain converter
- Low noise and low consumption
- High shielding to interfering 1,800 MHz LTE signals.
APPLICATIONS
Can be connected to two universal receivers, suitable for HD signal reception
TECHNICAL DATA
- Number of outputs 8
- Input frequency - GHz 10,7 ÷ 12,75
- Local oscillator frequency - GHz 9.75 / 10.6
- Output frequency - MHz 950 ÷ 1950 / 1100 ÷ 2150
- LTE filter @ 1800 MHz - dB 40 minutes
- Gain - dB 52 ÷ 65
- Polarity switching 13V - 18V / 0 - 22 KHz
- Noise figure - dB 0.1
- Supply voltage - DVC 11,5 ÷ 19
- Max. current consumption - mA 220
- Impedance - Ohm 75
- Output connector Type F
- Feed diameter - mm 40
- Dimensions (W x H x D) - 139 x 53 x 99 mm
- Weight - g 368
- Complies with EN 55032, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 303372-1, EN 62368-1, EN 50581.
Data sheet
- Type: Illuminators
- Version: 8 outputs
