Lifting bracket for photovoltaic structures SEL05 OB620393
ORB OB620393
8426709936488
The lifting bracket SEL05 OB620393 allows tilting photovoltaic modules on flat corrugated sheet metal roofs or on vaults, combining with the EASY WING SMALL profile for a stable, adjustable, and orderly installation.
-
Application: flat corrugated sheet metal roofs or on vaults
-
Compatibility: to be combined with EASY WING SMALL profile (bar or 420 mm pieces)
-
Inclination adjustment: through SEL 05 / SEL 10 / SEL 15 combination (positive or negative inclination)
-
Material: Aluminum AW6060 T6
-
Section area: 361 mm²
-
Width: 80 mm
-
Height: 54.2 mm
-
Depth: 38.8 mm.
€1.68
Items Available: 75
: 51
Frequently bought together
Lifting bracket SEL05: adjustable inclination on corrugated roofs
The lifting bracket for photovoltaic structures SEL05 (OB620393) is a specific component for installations on corrugated sheet metal (flat or on vaults) when it is necessary to modify the inclination of the modules. In many industrial and commercial roofs, the existing orientation or slope is not ideal for energy yield: the SEL bracket allows you to set a more favorable angle, improving the panel's exposure and facilitating the management of the plant layout.
Thanks to its lifting function, the bracket creates the correct height difference between the fixing points, making it possible to achieve a more efficient installation without resorting to bulky or complex structures.
-
Designed for flat corrugated roofs or on vaults
-
To be combined with the EASY WING SMALL profile (bar or 420 mm pieces)
-
Variable module inclination thanks to the combination of SEL brackets (05/10/15)
-
Possibility of positive or negative inclination based on configuration
-
Made of aluminum AW6060 T6: lightweight and corrosion-resistant
-
Compact and robust section: optimizes space and aesthetic appearance of the plant.
Modular system with EASY WING SMALL profile
The mounting system is based on the combination with the EASY WING SMALL profile, available in bar or in 420 mm pieces. The profile is secured to the roof and works in synergy with the SEL lifting bracket to ensure mechanical stability and orderly module fixing.
This architecture is particularly appreciated on site because it allows for a repeatable and clean installation, reducing assembly times and simplifying the alignment of the rows.
Positive or negative inclination with SEL combinations
One of the strengths of the SEL model is the ability to achieve different inclinations simply by varying the combination between the lower and upper lifting bracket. Using the SEL 05, SEL 10, SEL 15 variants, you can set:
-
positive inclination, to increase the panel angle relative to the slope
-
negative inclination, when it is necessary to correct the setup or manage plant constraints
This flexibility makes SEL05 a practical solution to optimize yield and adapt to structural constraints, obstacles, shading, or design requirements.
Material in aluminum AW6060 T6: durability and reliability
The bracket is made of aluminum AW6060 T6, an alloy frequently used in photovoltaic structures for its combination of mechanical strength, lightweight, and excellent corrosion resistance. It is an ideal choice for installations on metal roofs exposed to rain, humidity, and temperature fluctuations, contributing to the overall durability of the structure over time.
There are no reviews
Data sheet
- Type: Fixing Accessories
