Schneider XCSDMP 1NC+2NO NC scaled safety switch 5m cable XCSDMP7005
TSI XCSDMP7005
3389110972009
Schneider non-contact safety switch XCSDMP 1NC+2NO NC scaled with the following characteristics:
- Contact composition and type: 2 NC + 1 NO
- Contact operation: 1 NC staggered
- Cable composition: 6 x 0.25 mm²
- Cable length: 5 meters
- Number of poles: 3
- Approach directions: 3 directions
- Rated operating voltage: 24 V DC
- Rated insulation voltage: 100V DC
- Guaranteed operating distance: 8 mm
- Guaranteed operating distance: 20 mm
- Maximum rated operating current: 100 mA
- Rated impulse withstand voltage: 2.5 kV in accordance with EN/IEC 60947-5-1
- Short-circuit protection: 500 mA external cartridge fuse type gG (gl)
€73.79
Items Available: 14
: 13
The product is part of the XCS range, an offering of safety selector switches.
The coded magnetic selector helps protect the operator by immediately stopping any dangerous movement as soon as the distance between the selector and its magnet. It features staggered contacts, 2 normally closed + 1 normally open.
It is a standard selector switch with a rated operating current of 100mA and a rated operating voltage of 24V DC. It comes with 5m pre-wire for electrical connection.
The product is rated IP66 and IP67. It offers an electrical durability of 1.2 million cycles. Dimensions: 25 mm (width) x 13 mm (depth) x 88 mm (height); weight 0.18 kg.
It is ideal for all hazardous machines with free access that require zone protection for operator and machine safety.
Examples: packaging, handling, robotics, machine tools, presses, and automotive.
The product is UL, CSA and BG certified. It complies with UL 508, ISO 14119, EN/ISO 12100, EN/IEC 60947-5-1, EN/IEC 60204-1 and CSA C22.2 No 14.
The device can achieve up to: category 4 PL=e or SIL 3 (when combined with a PREVENTA XPS PL=e/SIL 3 safety unit). Electrical equipment must be installed, operated and maintained only by qualified personnel.
Protection of operators by stopping the light industrial machine with rapid downtime when opening the door with inaccurate indications and subject to frequent washing. Protection selectors with plastic casing for use on machines with low inertia. Specially designed for industrial machines with doors, covers or guards with inaccurate guidance.
Features:
- Electrical life: 1200000 cycles
- Switching capacity in mA: 0.1 to 100 mA
- Insulation resistance: 1000 M
- Interrupting capacity: 10 VA
- Switching frequency: 150 Hz
- Enclosure material: thermoplastic PBT
- Cable material: PVC
- Operating ambient temperature: -2585°C
- Storage temperature: -4085°C
- Vibration resistance: 10 gn (FA= 10150 Hz) complying with IEC 60068-2-6
- Shock resistance: 30 gn for 11 ms complying with IEC 60068-2-27
- Maximum sensitivity to magnetic fields: 0.3 mt
- Protection class against electrical discharge
- Class II in accordance with EN/IEC 61140
- IP degree of protection: IP66 complying with IEC 60529 - IP67 complying with IEC 60529
- Dimensions: height 88 mm width 25 mm depth 13 mm
- Weight: 180 grams
Security level:
- Up to category 4 With appropriate monitoring system properly wired conforming to EN/ISO 13849-1
- Up to PL = e With appropriate monitoring system correctly wired in accordance with EN/ISO 13849-1
- Can reach SIL 3 With appropriate monitoring system properly wired conforming to EN/IEC 61508
