Siemens 3VA1 125A 4-pole moulded case disconnector 3VA11 3VA11121AA420AA0
SIE 3VA11121AA420AA0
4042948800577
Siemens boxed underload disconnect switch, series 3VA1, with the following characteristics:
- Rated insulation voltage 800 V
- Operating voltage with DC nominal value 600 V
- Operating current 125A
- 4 poles
€306.06
Items Available: 3
: 2
Further Siemens RCBO combinations:
Frequently bought together
The new 3VA moulded case circuit breakers guarantee high selectivity, extremely compact dimensions and high breaking capacities. The different dimensional sizes up to 1000 A and more than 500 accessory components allow to satisfy all possible configurations of any application.
Features:
- Siemens Series
- Rated insulation voltage 800 V
- Operating voltage with DC nominal value 600 V
- Operating current 125A
- 4 poles
- Power loss max 38 W
- Mechanical service life (switching cycles) / tip 15,000
- Height 130 mm
- Width 101.6 mm
- Depth 70 mm
- Net weight 1.100 gr
- Degree of protection front side IP40
Ambient temperature
- During operation / min. -25 °C
- During operation / max. 70 °C
- During storage / min. -40 °C
- During storage / max. 80 °C
There are no reviews
Data sheet
- Type: Switches
- Poles: 4P
- Amps: 125A
