Product advantages:

• Very slim housing
• Reduced installation depth
• High luminous efficiency
• Energy savings of up to 60% (compared to luminaires using CFL lamps)
• Very homogeneous light
• Functional design
• Simple installation with quick connection
• Easy installation with integrated driver




Areas of application:

• Direct replacement for luminaires with compact fluorescent lamps
• General lighting
• Public areas
• Stairways
• Corridors
• Foyers
• Stores



Other technical characteristics:

• Inrush current: 17A
• Hourly inrush current T h50: 56 µs
• Maximum. NO. of lum. on circuit breaker: B16: A 44
• Maximum. NO. of lum. on circuit interruption: C16 A 56
• Maximum. NO. of lum. on circuit interruption: C10A 35
• Power factor λ: 0.50
• Total Harmonic Distortion: < 20%
• Protection Class: II
• Standard deviation of color matching: < 6 sdcm
• Photobiological safety group acc. to EN62778: RG0
• Photobiological safety group acc. to EN62471: RG0
• Beam angle: 120 degrees
• Dimensions: Diameter 225.00 mm - Height 30.00 mm
• Color: White
• Housing color: White
• Housing Material: Polycarbonate (PC)
• Cover Material: Polycarbonate (PC)
• Material of light-emitting surface: Polycarbonate (PC)
• Glow wire test according to IEC 60695-2-12: 650 °C
• Mercury content: 0.0 mg
• Ambient temperature range -20...+50 °C
• Temperature range during storage -30...+70 °C
• Connection type Screwless terminal block, 2-pole
• Type of protection IP20
• Protection class IK (shock resistance) IK03
• Mounting type Recessed
• Mounting location: Ceiling
• Application Environment: Indoor
• Mounting diameter: 210.0 mm
• Mounting depth: 50.0 mm
• Replaceable LED module: Not replaceable
• With light source YES
• Service life L70/B50 at 25 °C: 30000 hours
• Service life L80/B10 at 25 °C: 20000 hours
• Service life L90/B10 at 25 °C: 12000 hours
• Number of switching cycles: 50000
• Standard CE, CB,EAC
• Output current 295 mA
• ECG - Output ripple current: < 6.5%
