Raytech self-amalgamating insulation tape 9 meters 3-2001-00-13
RYT 3-2001-00-13
8032853650950
BT and MT Raytech self-amalgamating EPR insulation tape with the following characteristics:
- Width: 19 mm
- Thickness: 0.76 mm
- Length: 9 meters
- Color: Black
Used for insulating and sealing electrical connections even for high voltages (up to Um 72 kV).
Raytech self-amalgamating insulation tape 9 meters 3-2001-00-13
€11.80
€11.80
Tax included
Tax included
Pay in installments with Klarna
Items Available: 21
Ethylene-propylene (EPR)-based self-amalgamating insulating tape for high voltage.
Used for the insulation and sealing of electrical connections even for high voltages (up to Um 72 kV), it amalgamates rapidly by adapting to the underlying artifact forming a compact body, without vacuoles, particularly resistant to partial discharges (corona), with stable characteristics over time.
Joints should be protected with PVC tape or similar.
Characteristics:
- Tensile breaking load: 2.2 MPa min
- Elongation at break: 800% min
- Overload temperature: 130°C
- Operating temperature: 90°C
- Dielectric strength: 38 kV/mm min
- Volume resistivity: 1015 ? cm min
- Ozone resistance
- U.V resistance
There are no reviews
Data sheet
- Type:
- Tapes insulating
