Bosch Condensing Boiler 2300 W 24KW Natural Gas
JUN 7736901284
4057749433213
The Bosch Condens Condensing Boiler GC2300W 24 C 23 Natural Gas is an ideal solution for those seeking energy efficiency, quiet operation, and compact design. Perfect for single- and multi-family houses, condominium apartments and renovations, it provides maximum performance and savings:
-
Thermal power: 24KW, suitable for heating and domestic water
-
Fuels supported: Natural gas, LPG (with accessory) and hydrogen blends up to 20%.
-
Energy class: Heating: A - Domestic water: A
-
1:10 modulation ratio: Optimizes gas consumption for low heating and domestic water demands
-
Compact design: Fits any room, ideal for replacements and renovations
-
Perfect for rooms: Up to 150 sq. m.
-
Seasonal efficiency: 94%, among the highest for condensing boilers
-
Flue pipe kit: Coaxial M/F Ø60/100 for Bosch boilers not included
€1,182.91
Items Available: 9
: 1
Frequently bought together
Bosch Condens Condensing Boiler 2300 W 24KW with Natural Gas
Condens 2300 W is designed to find space anywhere: its small size makes it easy to install in any home environment, making it an ideal solution for modernization projects. Installing Condens 2300 W, even in the case of renovation, is very simple: its compactness makes it extremely versatile and, adapting to multiple geometries, it does not require moving the flue outlet. Various accessories are also available to support installation. Maintenance is also simplified, thanks to the possibility of removing the side panels and easily accessing the components.
Efficiency and reliability
Thanks to the Al-Si WB6 aluminum alloy primary exchanger, the boiler offers robustness and durability. The modulation system without mechanical parts ensures gas savings and constant comfort.
Advantages
- Compact size for retrofitting old systems or installation in small spaces
- Meets all requirements for comfort and savings thanks to wide continuous power modulation
- Extremely quiet: only 44 dB
- Manageable via App, in conjunction with the EasyControl smart thermostat.
Best-in-class reliability:
- Robustness and reliability of the compact wall-mounted condensing boiler are guaranteed thanks to the Al-Si WB6 aluminum alloy primary exchanger.
1:10 modulation ratio:
- The modulation ratio is up to 1:10, and is constant over time thanks to the modulation system without mechanical parts. This is to achieve greater gas savings and high comfort even with low domestic water demands.
Maximum seasonal efficiency:
- The highest seasonal efficiency obtainable from a condensing boiler (94%). Possibility of having a Class A+ boiler with the combination of a modulating temperature controller with climatic function.
Extremely compact:
- The extremely compact size of this boiler makes it the ideal replacement when you decide to change your old one.
Modern and functional, both inside and out:
- Condens 2300 W combines the use of first-rate materials, designed to last, with a sophisticated and functional design, which makes the modernity of this boiler evident both in front and behind the shell. The components are first-rate, starting with the aluminum silicon exchanger, a guarantee of robustness and reliability over time.
Simply efficient in all circumstances:
- Condens 2300 W is synonymous with efficiency thanks to the modulating burner with a 1:10 range that automatically adapts to the heat demand of the moment, achieving very high seasonal energy efficiency for space heating, with values of up to 94 percent. Again thanks to the wide modulation, this boiler also provides a lot of hot water with constant temperature. In addition, Condens 2300 W, when combined with modulating temperature control with climate function, falls into energy class A+ and allows access to tax incentives of up to 65%. Finally, compatibility with the new EasyControl smart thermostat allows the system to be conveniently controlled remotely via smartphone, thanks to the dedicated App.
General Specifications
| Feature | Detail |
|---|---|
| Min. rated heat output (80/60 °C) | 3 kW |
| Maximum rated heat output at part load (80/60 °C) | 24 kW |
| Max. rated heat output (50/30 °C) | 25 kW |
| At 30% of rated heat output and at a low temperature regime | 8.0 kW |
| Max. flow temperature | 82°C |
| Expansion tank volume | 6 l |
| Max. nominal heating load | 24.5 kW |
| Electrical connection | 230 V |
| Electrical frequency | 50 Hz |
| Type of protection (EN 60529) | IPX4D, B23/B33: IPX0 |
| Max. power consumption | 90 W |
| Net weight | 37 kg |
| Width | 400 mm |
| Height | 710 mm |
| Depth | 300 mm |
| Heating flow/return connection | 3/4 Zoll |
| Mains gas connection | 3/4 Zoll |
| Flow/return flow connection | 1/2 Zoll |
| Rated heat output | 24 kW |
| Seasonal energy efficiency of room heating | 94 % |
| Energy efficiency of water heating | 85 % |
| H2 Ready | No |
| Suitable fuels | Gas |
Efficiency and Consumption
| Feature | Detail |
|---|---|
| Efficiency at rated heat output (high temperature) | 88,2% |
| Efficiency at 30% of rated heat output (low temperature) | 98,6% |
| Auxiliary electricity consumption (full load) | 0.037 kW |
| Auxiliary electricity consumption (partial load) | 0.010 kW |
| Auxiliary electricity consumption (standby) | 0.0027 kW |
| Standby heat loss | 0.048 kW |
| Nitrogen oxide (NO) emissions | 28 mg/kWh |
| Sound power level (indoor) | 44 dB(A) |
| Declared load profile | XL |
| Daily power consumption | 0.122 kWh |
| Annual electricity consumption (AEC) | 27 kWh |
| Daily fuel consumption | 23.032 kWh |
| Annual fuel consumption (AFC) | 18 GJ |
| Energy efficiency of domestic hot water production | 85% |
There are no reviews
Data sheet
- Type: Boilers
- Model: Natural gas
- Thermal power: 24 kW
- Energy class: A
- Series: Condens
