Telemecanique limit switch body ZCKJ 1NO+1NC ZCKJ1

Schneider
Schneider
SNR ZCKJ1 3389110646108

Schneider Telemecanique limit switch body, with the following characteristics:

  • Body type: fixed
  • Body material: metal
  • Cable entry: 1 tapped entry for 13.5 Pg cable collar
  • Number of poles: 2
  • Contact composition and type: 1 NC + 1 NO
  • Contact operation: snap
  • Number of phases 1-1 position
  • Contact material: silver plated contacts
  • Local display: without
Do you have questions about this product or did you not find what you were looking for? Ask us!
Telemecanique limit switch body ZCKJ 1NO+1NC ZCKJ1
€31.69
€31.69

€31.69
Tax included
Calculate shipping cost
Out of stock
Further availability of the manufacturer
Incoming
€31.69

Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Other technical features:

  • Electrical connection: screw terminals, clamping capacity: 1 x 0.34...2 x 1.5 mm²
  • Positive opening: with
  • Min. actuation speed: 0.01 m/min
  • Conventional thermal current in box [Ithe]: 10A
  • Resistance between terminals: 0.25 mOhm in accordance with IEC 60255-7 category 3
  • Short-circuit protection: 10A fuse cartridge, type gG
  • Type of electrical circuit: signal light module 2 neon lights "AC", 110/120 V (95...130 V) service life: 20000 H
  • Description ISO terminals No. 1: (11-12)NC, (13-14)NO
  • IP degree of protection: IP66
  • IK degree of protection: IK07
  • Operating ambient temperature: -25/+70 °C for standard environment
  • Storage temperature: -40/+70 °C
  • Environmental characteristics: standard environment

Rated use current [Ie]:

  • 3A at 240 V, AC-15, A300 in accordance with EN/IEC 60947-5-1 appendix A
  • 0.27A at 250 V, DC-13, Q300 complying with EN/IEC 60947-5-1 appendix A

Rated insulation voltage [Ui]:

  • 500V (pollution degree 3) complying with IEC 60947-1 for contact blocking
  • 300V complying with CSA C22.2 No 14 for contact block
  • 300V complying with UL 508 for contact block

Rated impulse withstand voltage [Uimp]:

  • 6 kV complying with IEC 60664
  • 6 kV complying with IEC 60947-1

Electrical endurance:

  • 5000000 cycles, DC-13 120 V, 4 W, operating range <60 cycles/m, load factor: 0.5 complies with IEC 60947-5-1 appendix C
  • 5000000 cycles, DC-13 24 V, 10 W, operating range <60 cycles/m, load factor: 0.5 complying with IEC 60947-5-1 appendix C
  • 5000000 cycles, DC-13 48 V, 7 W, operating range <60 cycles/m, load factor: 0.5 complies with IEC 60947-5-1 appendix C

Dimensions and weight:

  • Width 40 cm
  • Height 81.5 cm
  • depth 44 cm
  • Weight: 0.34 kg

There are no reviews

Data sheet

Type:
Limit switch
