Ziggiotto 90 degree grooved bend 2 inches 50mm PN500 B0090060

Ziggiotto
Ziggiotto
914 B0090060

Ziggiotto 90-degree grooved bend designed for hydraulic pressure systems up to 500 PSI. The ideal solution for quick, safe and reliable connection without threads or welding, with the following features:

  • Bend: 90 degrees for grooved piping

  • Nominal diameter: 2 inches (50 mm)

  • Outer diameter: 60.3 mm

  • Nominal pressure: PN500

  • Compatible with: Water and glycol systems (max 15%)

  • Certifications: UL / FM

Do you have questions about this product or did you not find what you were looking for? Ask us!
Ziggiotto 90 degree grooved bend 2 inches 50mm PN500 B0090060
€4.76
€4.76

€4.76
Tax included
Calculate shipping cost
Items Available: 14
Further availability of the manufacturer
€4.76

Buy it within and receive it from Monday, 22 December
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Grooved bend hydraulic joint solution

The Ziggiotto 90-degree grooved bend is a technological and cost-effective alternative to traditional connection methods such as welding, flanging or threading. Thanks to the grooved system, installation is quick and safe, ensuring a solid and easily inspected connection.

Ease of installation and maintenance

The groove connection is simple to make and allows easy installation and disassembly, making maintenance operations extremely convenient. This is particularly advantageous in installations where modularity and expandability are key factors.

Applications and compatibility

Suitable for a wide range of applications in hydraulic distribution systems, it is not suitable for use with potable water. Instead, it is perfect for circuits that use water mixed with glycol (up to 15 percent), making it particularly useful in fire protection systems, heating, air conditioning or industrial cooling systems.

Technical Specifications Ziggiotto Grooved bend

Type 90-degree grooved elbow
Nominal diameter 2 inches (50 mm)
Pipe outer diameter 60.3 mm
Nominal pressure rating (PN) 500 PSI
Fluid compatibility Water and glycol (up to 15%)
Certifications UL / FM
Grooving material Steel - suitable for rolling or turning
Use Plumbing systems, fire protection, HVAC (excluding potable water)

There are no reviews

Data sheet

Type:
Bends
Model:
90 Degrees
Connections:
2 inches
