Specifications:

• Video inputs 4 (4PoE) @6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF
• Main video outputs 1 (VGA), 1 (HDMI), 1920x1080
• Video compression H.265S / H.265+ / H.265 / H.264
• Frame rate in playback / recording 30fps@6MP
• Included hard disk capacity 1TB (10TB max)
• Maximum number of channels played back simultaneously 1@6MP, 4@Full HD
• Supported protocols DDNS, DHCP, HTTP, HTTPS, SMTP, TCP/IP, ONVIF
• DHCP IP assignment, manual
• Max bandwidth (Mbps) 40
• Remote control by browser Internet Explorer, Firefox, Chrome, Safari
• Remote control from Comelit CCTV Manager software
• Remote control from mobile APP Comelit CCTV Users connected simultaneously 32
• Main functions Video analysis (only with dedicated cameras)
• Alarm system function
• Motion detection function (zones) Yes
• Type of connections/ports 1xEthernet 10/100 Mbit/s, 2xUSB 2.0, 4 x Ethernet PoE 10/100 Mbit/s
• Fanless Yes
• Machine power consumption (no HDD) (W) 5
• Maximum power consumption per port
• POE (W) 30 POE total power (W) 40
• Maximum distance in long range mode (m) 100
• Supply voltage (VDC) 48
• Dimensions: Height (mm) 42 Width (mm) 255 Depth (mm) 222
• Product weight (g) 1.6
• Type coating materials Metallic
• Product color Black
• Operating temperature (°C) -10 to 50
• Operating humidity (RH max) (%) 25 ÷ 90
• Included accessories Power supply unit, Mouse
