Panduit Opticom Fiber Optic Drawer 6 Port SC 1RU OM1 OM3 OM4 OS2 FD1W6AQDSCZ

Panduit EDS LAN
Panduit EDS LAN
PAN FD1W6AQDSCZ

Pre-loaded and ready-to-use Panduit Opticom fiber box for efficient and secure management of fiber terminations with the following features:

  • Enclosure: 1RU preconfigured for 6 ports with duplex SC adapters.

  • Compatible with: OM1, OM3, OM4 multimode fiber and OS2 singlemode fiber

  • Mounting on: EIA-310/IEC 60297 compliant 19-inch rack

  • Frame: 2-piece metal with accessories included

  • Drawer: Sliding for full access to connections

Offer expires in
Do you have questions about this product or did you not find what you were looking for? Ask us!
Panduit Opticom Fiber Optic Drawer 6 Port SC 1RU OM1 OM3 OM4 OS2 FD1W6AQDSCZ
€143.19
€138.90
€138.90

Lowest price in 30 days:
€143.19
Save 3%
€138.90
Tax included
Calculate shipping cost
Offer expires in
Items Available: 4
Further availability of the manufacturer
€138.90

Buy it within and receive it from Friday, 27 February
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Panduit fiber drawer preloaded system for rapid installations

The Opticom fiber drawer is a ready-to-use solution designed to simplify fiber termination management in data centers and telecom rooms. With preinstalled duplex SC adapters, it enables immediate cabling without complex assemblies.

Rugged construction and complete accessibility

The two-piece metal frame includes a sliding drawer that extends up to 300mm, providing full access to terminations for maintenance, modification, and patching operations. Screen-printed labeling allows clear identification of fiber channels and enclosure.

Versatility in cable entry modes

Supports multiple input modes: PG11 ferrules, 30mm conduits, 20mm holes, and 5mm blown fiber ducts, making it extremely flexible during installation and compatible with different network configurations.

Compatibility with multimode and singlemode fiber

The enclosure is suitable for use with OM1, OM3, OM4 (multimode) and OS2 (singlemode) fiber, providing maximum flexibility of use in high connection density environments.

Recommended Applications.

  • Patch panels in data rooms and telecommunications

  • Transition between backbone and horizontal cabling

  • Active equipment interconnection in FTZ networks

  • Splicing solutions between provider fiber and in-building plant

Technical Specifications Panduit Fiber Drawer

Number of ports 6 SC duplex
Compatible fiber OM1, OM3, OM4, OS2
Body/adapter color Black / Water
Mounting 19" rack EIA-310 / IEC 60297
Height 43.9 mm
Width 444.5 mm
Depth 308.2 mm
Material Metal, 2-piece structure
Standards Compliant EIA-310, IEC 60297 (not subject to RoHS)
Accessories included Mounting kit, FMS1, conduits, cable ties

There are no reviews

Data sheet

Type:
Fiber optic patch panels
Doors:
6
