Gewiss vertical interlocked socket 2P 16A IP67 24V GW66259N

Gewiss
GEW GW66259N 8011564741546

Gewiss vertical interlocked fixed socket, with the following characteristics:

  • Output voltage: 20-25V
  • Nominal power: 160VA
  • Rated current 16A
  • Number of poles: 2P
  • Frequency: 50 Hz
  • Degree of protection IP67
Do you have questions about this product or did you not find what you were looking for? Ask us!
Gewiss vertical interlocked socket 2P 16A IP67 24V GW66259N
€156.24
€156.24

€156.24
Tax included
Calculate shipping cost

€156.24

Two-year warranty
Easy return within 14 days

Features:

  • Gewiss Series
  • Typology: vertical
  • Protection: safety transformer
  • With bottom
  • Thermopressure with ball: 125 °C (IB socket) - 80 °C (Bottom box)
  • Shock resistance: IK08
  • Operating temperature: -25 +40 °C
  • Electrocod code: 2222
  • Glow wire test; 850 °C (Socket IB) - 650 °C (Bottom box)
  • Color: violet
  • Ware number 85366990

Data sheet

Type:
Interlocked switch socket outlets
Voltage:
230/24VAC
Poles:
2P
Degree of protection:
IP67
Installation:
Wall/Recessed
