Gewiss interlocked socket 3P+N+E 32A IP44 380V without box GW66120


GEW GW66120 8011564029262

Gewiss fixed interlocked socket, with the following characteristics:

  • Rated voltage: 380-415V
  • Number of poles: 3P+N+T
  • Frequency: 50/60 Hz
  • Rated current 32A
  • Degree of protection IP44
  • Without base
  • Without fuse base
  • Typology: horizontal
Request info about this product

Gewiss interlocked socket 3P+N+E 32A IP44 380V without box GW66120

€57.38
€57.38

Gewiss interlocked socket 3P+N+E 32A IP44 380V without box GW66120

€57.38
Tax included
klarna Pay in installments with Klarna
qty

Gewiss interlocked socket 3P+N+E 32A IP44 380V without box GW66120

€57.38

Buy it within and receive it from Thursday, 13 June
Two-year warranty
Secure Payment
Easy return within 14 days

Features:

  • Gewiss Series
  • Thermopressure with ball: 125 °C
  • Shock resistance: IK08
  • Operating temperature: -25 +40 °C
  • Protection: NO (SBF)
  • Electrocod code 2220
  • Glow wire test: 850 °C (active parts) - 650 °C (passive parts)
  • Color: red
  • Reference h: 6
  • Ware number 85366990

Data sheet

Type:
Interlocked switch socket outlets
Voltage:
380/415VAC
Poles:
3P+N+T
Degree of protection:
IP44
Installation:
Wall/Recessed
