Urmet flush-mounted 4-channel radio transmitter E4BPP Yokis 5454427
UTD 5454427
3760054544277
Urmet Yokis radio transmitter, flush-mounted, with 4 independent channels, with the following features:
- Battery: type CR2032, lithium
- Battery life: > 7 years
- Channels available: 4
- Number of receivers/channel: 4 in direct mode; unlimited in 'Bus Radio' mode
- Frequency: 2.4 GHz
- Transmission: Bidirectional with notification led on the transmitter. Operating temperature: - 10°C to +50°C
- Relative humidity: maximum 70%
- Degree of protection: IP54
- Dimensions (WxHxD): 28,5x40x11,5 mm
€48.52
Items Available: 11
Frequently bought together
Range: 250 meters in free field of view without obstacles. Range reduction in the presence of metal elements, crossing walls or bulkheads.
The module can be wired behind the buttons of any civil series on the market and is compatible with all Yokis Radio receivers.
In case the receiver is a MTR2000ERP/X or a MTR2000MRP/X it can be connected both with buttons and switches.
The MVR500ERP radio dimmer works exclusively with push buttons.
The left channel (brown wire) and the right channel (green wire) are totally independent.
To control the shutters, the transmitter can be connected to a non-interlocked double push-button (up-down). In this case only one channel is available for the transmitter.
Data sheet
- Type: Radio Modules
