Chint Circuit Breaker NXB-63S 1P+N 25A 4.5kA C 2M 296751

Chint
Chint
CHT 296751 6941716447526

Chint NXB-63S Circuit Breaker, overload and short-circuit protection for domestic and civil installations, with the following characteristics:

  • Number of Poles: 1P+N

  • Rated current: 25 Amps

  • Tripping curve: C

  • Rated voltage: 230 Vac

  • Interrupting capacity: 4.5 kA

  • Number of Modules: 2

  • Degree of protection: IP20

Do you have questions about this product or did you not find what you were looking for? Ask us!
Chint Circuit Breaker NXB-63S 1P+N 25A 4.5kA C 2M 296751
€6.55
€6.55

€6.55
Tax included
Calculate shipping cost
Items Available: 3
Further availability of the manufacturer
€6.55

Buy it within and receive it from Monday, 22 December
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Chint circuit breaker reliable and compact protection for civil installations

The NXB-63S circuit breaker is designed to protect terminal electrical circuits against overcurrents, such as overloads and short circuits. It is part of the NXB-63S series, known for its reliability, efficiency and ease of installation, ideal for civil, domestic and small commercial electrical installations.

C curve: the right choice for mixed loads

Curve C allows the breaker to tolerate temporary overcurrents up to 5-10 times the rated current, making it perfect for lines that supply devices with peak loads, such as appliances, outlets and lighting.

Compatibility with accessories and improved safety

This model is compatible with a range of optional accessories for circuit monitoring and management:

  • AX-X1 auxiliary contact

  • AL-X1 alarm contact

  • SHT-X1 trip coil

  • Minimum voltage coil UVT-X1

  • Note: not compatible with differential modules

Technical Specifications Circuit Breaker NXB-63S

Series NXB-63S
Number of poles 1P+N
Rated current 25 A
Tripping curve C
Rated voltage 230 Vac
Rated frequency 50/60 Hz
Isolation voltage 500 Vac
Impulse voltage (Uimp) 4 kV
Interrupting capacity (Icn) 4.5 kA
Extreme breaking capacity (Icu) 6 kA
Service rating (Ics) 4.5 kA
Limitation class 3
Power dissipation 4,5 W
Number of modules 2
Degree of protection IP20
Mounting On DIN rail

There are no reviews

Data sheet

Voltage:
230VAC
Modules:
2
Poles:
1P+N
Curve:
C
Breaking capacity:
4.5KA
Degree of protection:
IP20
Amps:
25A
Circuit Protections:
Circuit breakers
