Obo Surge protector 20 kA 3+NPE IP20 5095253

Obo Bettermann
Obo Bettermann
OBO 5095253 4012196161331

Obo type 1+2 surge protector with the following characteristics:



  • Maximum continuous AC voltage: 280V
  • Maximum fuse rating: 160A
  • Torque: 4 Nm
  • Number of poles: 4
  • Poles version: 3+N/PE
  • Minimum distance: 1.5mm
  • Degree of protection: IP20



Application: main distribution board and secondary board.

Do you have questions about this product or did you not find what you were looking for? Ask us!
Obo Surge protector 20 kA 3+NPE IP20 5095253
€175.19
€175.19

€175.19
Tax included
Calculate shipping cost
Items Available: 108
Further availability of the manufacturer
€175.19

Buy it within and receive it from Thursday, 8 January
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

The surge arrester is a tool that can be mounted inside the electrical panel, thus upstream of the house system. Its use allows the electrical system on which it is installed to be protected.



The surge arrester will protect the entire system from surges, surges and spikes of electricity that may come from the power line operator, or from atmospheric phenomena such as lightning. These power anomalies can cause serious damage to devices connected to outlets.



A surge of electricity can cause the hardware of a pc to break, or short circuit the boards of smartphones, tablets, and home appliances. In the event that the flow of energy suddenly increases dramatically, human life may even be in danger due to electrocution. To prevent this from happening, it is therefore advisable to install a surge arrester.


Features:

  • N-PE successive current extinguishing capacity: 0.1 kA
  • Test class according to EN 61643-11: Type 2
  • Rated leakage current (8/20 µs): 20 kA
  • Rated leakage current (8/20 µs) L-N: 20 kA
  • Rated leakage current (8/20 µs) N-PE: 40 kA
  • Rated maximum discharge current (8/20 ?s): 40 kA
  • Rated maximum discharge current (8/20 ?s) L-N: 40 kA
  • Maximum rated discharge current (8/20 ?s) N-PE: 60 kA
  • Mounting mode: 35 mm Omega profile
  • Short-circuit resistant
  • Cross-section of flexible conductor (fine-stranded) max: 35 mm²
  • Cross-section of flexible conductor (fine-stranded) max: 2 AWG
  • Section of flexible conductor (fine-stranded) min: 1.5 mm²
  • Flexible conductor cross-section (fine-stranded) min: 16 AWG
  • Rigid conductor cross-section (solid/braid wire) max: 35 mm²
  • Rigid conductor cross-section (solid/braided cable) max: 2 AWG
  • Rigid conductor cross-section (solid/braided cable) min: 16 AWG
  • Operating temperature: -40/+80 degrees
  • Response time: <25 ns
  • Maximum continuous voltage (L-N): 280 V
  • Maximum continuous voltage (N-PE): 255 V
  • Maximum continuous AC voltage: 280
  • Rated AC voltage (50/60 Hz): 230 V
  • Line type for surge protectors: AC power line
  • Rated discharge current (8/20 µs): 60 kA
  • Overall protection level L-PE: 1.5 kV
  • Maximum grid overcurrent protection: 160 A gL/gG
  • Short-circuit with maximum grid overcurrent protection: 50 kA eff
  • Rigid conductor cross-section (solid/braided cable) min: 1.5 mm²



Advantages:

  • Installation for overvoltage protection according to VDE
  • Discharge capacity up to 40 kA (8/20) per pole with high-performance varistors
  • Modular, withdrawable complete with disconnection system and optical operation display
  • Plug-in connection with vibration protection and voltage coding

There are no reviews

Data sheet

Modules:
4
Poles:
4P
Version:
1/2
Model:
AC
Circuit Protections:
Surge protectors
