Siemens pure differential switch 2 poles 25A 300mA AC type 2 modules 5SV46120
SIE 5SV46120
4001869429854
Pure differential switch (circuit breaker) Siemens, 2 modules, DIN connection (universal for any switchboard on the market), 2P poles, 25 amperes, differential current Idn 300mA, voltage 230 Vac, AC differential type.
€52.68
Items Available: 151
: 34
The pure earth leakage circuit breaker is used to protect people and not the equipment. The moment a person goes to touch it, it creates a circuit with the earth. The current instead of remaining in the domestic circuit, uses the human body to go to earth.
The residual current circuit breaker, also called circuit breaker, is a device in your electrical system. It is able to open the circuit, i.e. to interrupt the supply of energy, when the current is accidentally lost.
A pure residual current circuit breaker offers protection in case of current leakage but not in case of overvoltage. For this type of problem, a circuit breaker is required instead.
The earth leakage circuit breaker type AC, operates only with alternating current. Almost all civil installations fall into this category.
Features:
- Siemens series
- Voltage 230 Vac
- Current In 25A
- Differential current Idn 300mA
- AC differential type
- 2 modules
- 2P
- Degree of protection IP20, for installation in distribution board, with conductors connected
- Frequency of use 50 Hz
- Height 90 mm
- Width 36 mm
- Depth 70 mm
- Recessed depth 70 mm
- Type of mounting DIN rail (REG)
- Any mounting position
- Tightening torque/with screw terminals min 2.5 Nm - max 3 Nm
- Net weight 203 g
Ottimo prodotto tutto perfetto come da descrizione
PRODOTTO OTTIMO CONOSCIUTO PERCHE' COMPRATO ALTRE VOLTE.
Ottimo prodotto come da descrizione........
Prodotto come da descrizione, in linea con le mie attese
È un ottimo prodotto, lo consiglio certamente
sicuramente ottimo rapporto qualita purezzo
siemens e' comunque un buon prodotto un marchio storico
Beh, difficile da commentare, l'ho montato e sta svolgendo la sua funzione come ci si aspetta. Confezione sigillata originale ovviamente...
Tutto ok
COME DESIDERATO
Data sheet
- Voltage: 230VAC
- Modules: 2
- Poles: 2P
- RCD Type: AC
- Differential current : 0.3A
- Amps: 25A
- Circuit Protections: Residual current devices
