Italweber fuse holder for NH fuses Type 1P NH-2 2541210
ITW 2541210
8024873026310
Italweber fuse holder, with the following characteristics:
- Ideal for knife-edge fuses NH series
- Nominal voltage 690 Vac / 700 Vdc
- 1 pole
- Current In 400A
- Ideal for single and three-pole families
- Rated current up to 630A
- Resistance to short circuit current 50kA (100kA peak)
- Maximum power dissipation 45W per pole
![](https://www.elettronew.com/41448-large_default/italweber-fuse-holder-for-nh-fuses-type-1p-nh-2-2541210.jpg)
Italweber fuse holder for NH fuses Type 1P NH-2 2541210
€27.03
€27.03
Tax included
Tax included
![klarna](/../img/logo-klarna-list.png)
Items Available: 3
Features:
- Italweber series
- Ideal for knife-edge fuses NH series
- Nominal voltage 690 Vac / 700 Vdc
- 1 pole
- Current In 400A
- Ideal for single and three-pole families
- Screw fixing (NHD), for DIN rail mounting (NHU), with microswitch (NHU/MS)
- Dimensions NH-00, NH-0, NH-1, NH-2, NH-3
- Compliant with standards IEC 32-1, IEC 32-4, IEC 60269-1, IEC 60269-2, DIN 43620
- Plastic body (polyamide + 25% glass fibres)
- Degree of self-extinguishing UL94-V0
- Contacts in silver-plated copper
- Bolting material steel quality 8.8
- Rated current up to 630A
- Operating temperature -20°C / +70°C
- Resistance to short circuit current 50kA (100kA peak)
- Maximum power dissipation 45W per pole
Data sheet
- Type:
- Fuse holder
- Voltage:
- 690VAC
- Poles:
- 1P
- Amps:
- 400A
