Eaton 20A 1P+N 6kA 300mA Residual Current Operated Circuit Breaker Curve C Type AC 2M 177634
EAO 177634
4015081720972
Eaton Residual Current Operated Circuit Breaker is a compact and highly efficient device that offers complete protection from short circuits, overloads and current leakage. It is ideal for domestic, commercial and tertiary applications, ensuring maximum safety and reliability, with the following features:
-
Rated current: 20A
-
Number of poles: 1P+N
-
Operating voltage: 240V AC
-
Differential current: 300mA
-
Interrupting capacity: 6 kA
-
Tripping curve: C
-
Differential type: AC
-
Number of modules: 2
-
Degree of protection: IP20
€68.05
Items Available: 2
: 1
Comprehensive protection for your system
The Eaton RCBO combines three essential functions in one device:
- Magnetic protection: intervenes quickly in the event of a short circuit, preventing damage to cables and reducing the risk of fire
- Thermal protection: protects against electrical power overloads, ensuring safe operation even with multiple appliances connected at the same time
- Differential (life-saving) protection: with 300mA sensitivity, it effectively protects people from current leakage, preventing dangerous electric shocks
Eaton RCBO: C curve, safety and easy installation
The Eaton Differential Circuit Breaker, offers a complete and safe solution for domestic and commercial electrical systems. With its combined magnetic, thermal and differential protection, it provides high safety standards, ease of installation and long-term reliability.
C-Curve and Differential Protection Type AC
Curve C provides optimal protection in circuits with mixed loads, such as household outlets and lighting systems. It is perfect for loads with medium inrush currents (5-10 times rated current), preventing unwanted trips during normal operation.
The AC-type characteristic ensures fast and effective tripping in the presence of alternating sinusoidal differential currents, both sudden and gradually increasing, in accordance with IEC EN 61008-1 standards.
Easy installation and reliability over time
Compact size (2 modules): ideal for electrical panels with limited space. Quick DIN rail mounting: ease of installation and maintenance. IP20 degree of protection: ideal for indoor environments, offers safety against accidental contact.
Eaton RCBO Technical Specifications
| Feature | Value |
|---|---|
| Rated current | 20A |
| Number of poles | 1P+N |
| Rated voltage | 240V AC |
| Rated frequency | 50 Hz |
| Rated differential current | 300mA |
| Interrupting capacity | 6 kA |
| Differential type | AC |
| Tripping curve | C |
| Number of modules | 2 |
| Degree of protection | IP20 |
| Overvoltage category | III |
| Pollution degree | 2 |
| Ambient operating temperature | -25/+40 degrees |
| Dimensions (HxWxD) | 75x35x80 mm |
Buon prodotto, compatto, ma bello tosto. È più massiccio dei classici gewiss e bticino.
Data sheet
- Modules: 2
- Poles: 1P+N
- Breaking capacity: 6KA
- RCD Type: AC
- Differential current : 0.3A
- Amps: 20A
- Circuit Protections: RCBO
