Cylindrical fuse Italweber 14 x 51 mm CH14 aM 10A 690V 1432010


ITW 1432010 8024873002086

Italweber cylindrical fuse, with the following characteristics:

  • Fuse gauge dimensions 14 x 51 mm
  • Fuse series CH14
  • Intervention characteristic aM
  • Rated current 10A
  • Rated voltage 690 Vac
  • Breaking capacity 80kA
Request info about this product

Cylindrical fuse Italweber 14 x 51 mm CH14 aM 10A 690V 1432010

€1.71
€1.71

Cylindrical fuse Italweber 14 x 51 mm CH14 aM 10A 690V 1432010

€1.71
Tax included
klarna Pay in installments with Klarna
qty

Cylindrical fuse Italweber 14 x 51 mm CH14 aM 10A 690V 1432010

€1.71

Buy it within and receive it from Wednesday, 10 April
Two-year warranty
Secure Payment
Easy return within 14 days

An electrical fuse (simply called a fuse) is an electrical device that protects a circuit from overcurrents (caused, for example, by short circuits). When an overcurrent occurs, the filament melts causing the circuit to open.

Features:

  • Italweber Series
  • Fuse gauge dimensions 14 x 51 mm
  • Fuse series CH14
  • Intervention characteristic aM
  • Compliant with standards CEI 32-1, CEI 32-4, IEC 60269-1, IEC 60269-2
  • Rated current 10A
  • Rated voltage 690 Vac
  • Steatite body
  • Contacts in silvered copper
  • Breaking capacity 80kA

Data sheet

Type:
Cylinder fuses
Size:
14X51
Voltage:
690V
Amps:
10A
Material:
Ceramic
