Bticino circuit breaker 1P+N 16A 2 modules FA81NC16

Bticino
Bticino
BTI FA81NC16 8005543471630

Bticino circuit breaker, 2 modules, DIN connection (universal for any switchboard on the market), poles 1P+N, 16 amperes, breaking capacity 4.5kA, voltage 230 Vac, curve C.

Do you have questions about this product or did you not find what you were looking for? Ask us!
Bticino circuit breaker 1P+N 16A 2 modules FA81NC16
€20.85
€20.85

€20.85
Tax included
Calculate shipping cost
Items Available: 24
Further availability of the manufacturer
€20.85

Buy it within and receive it from Monday, 22 December
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot
Curve C, trip threshold 5 to 10 times In, for application of ohmic-inductive circuits with medium inrush currents. It is widely used in domestic installations.


A circuit breaker is a safety device capable of automatically (i.e. without external intervention) interrupting the flow of electric current in an electric circuit in the event of an overcurrent.


Features:

  • Bticino series
  • Voltage 230 Vac
  • Current In 16A
  • Interrupting capacity Icn 4.5kA
  • Tripping curve C
  • 2 modules
  • Poles 1P+N
  • Height 83 mm
  • Width 35.6mm
  • Depth 76 mm
  • Maximum cable cross-section 25/35mmq
  • Degree of protection IP20

Un prodotto ottimo che l'ho conosco da tempo

Read all reviews

Data sheet

Voltage:
230VAC
Modules:
2
Poles:
1P+N
Curve:
C
Breaking capacity:
4.5KA
Amps:
16A
Circuit Protections:
Circuit breakers
