Abb Residual Current Operated Circuit Breaker 1P+N 20A 4.5kA Curve C 2M S598408

Abb
Abb
ABB S598408 4016779598408

Abb Residual Current Operated Circuit Breaker S201L is a safety device designed to protect electrical systems from overloads and short circuits. Ideal for residential and small commercial installations, with the following features:

  • Rated current: 20 amps

  • Number of poles: 1P+N

  • Operating voltage: 230V

  • Interrupting capacity: 4.5 kA

  • Tripping curve: C

  • Number of modules: 2

  • Degree of protection: IP20

  • DIN rail mounting, suitable for any switchboard on the market

Do you have questions about this product or did you not find what you were looking for? Ask us!
Abb Residual Current Operated Circuit Breaker 1P+N 20A 4.5kA Curve C 2M S598408
€14.48
€14.48

€14.48
Tax included
Calculate shipping cost
Items Available: 48
Further availability of the manufacturer
€14.48

Buy it within and receive it from Monday, 22 December
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Abb RCBO Safe and selective, easy installation and universal compatibility

Reliable protection against overloads and short circuits

This circuit breaker automatically breaks the circuit in the event of an overcurrent or short circuit, preventing damage to electrical systems and ensuring safety for users.

C curve: effective protection and optimal selectivity

The C-curve trip characteristic allows overcurrents up to 5-10 times the rated current to be tolerated, reducing untimely trips and ensuring effective protection for mixed loads.

Easy installation and universal compatibility

Thanks to DIN rail mounting, the circuit breaker is compatible with any standard switchboard, facilitating installation in new installations or replacement of existing devices.

Abb RCBO Technical Specifications

Feature Value
Rated current 20 A
Rated voltage 230 V AC
Tripping characteristic C
Number of poles 1P+N
Number of modules 2
Type of input voltage AC
Impulse withstand voltage 4.5 kV
Rated frequency 50/60 Hz
Electrical resistance 10000 cycles
Mechanical resistance 20000 cycles
Overvoltage category III
Ambient temperature -25/+55 degrees
Degree of protection IP20
Pollution degree 2
Width 35 mm
Height 88 mm
Depth 69 mm

Interruttore automatico perfetto come da descrizione.

Prodotto conforme alla descrizione ed all'ordine

Ottimo MAGNETOTERMICO 2 MODULI 1P N 4,5KA 20A S598408:

Read all reviews

Data sheet

Voltage:
230VAC
Modules:
2
Poles:
1P+N
Breaking capacity:
4.5KA
Amps:
20A
Circuit Protections:
Circuit breakers
