Abb Circuit Breaker 1P+N0 32A 46kA Curve C 2M S531801
ABB S531801
4016779531801
Abb Circuit Breaker is a safety device designed for the protection of domestic and commercial electrical systems. It provides reliable automatic interruption in the event of an overload or short circuit, with the following characteristics:
-
Rated current: 32 amps
-
Number of poles: 1P+N
-
Operating voltage: 230V
-
Interrupting capacity: 6 kA
-
Tripping curve: C
-
Number of modules: 2
-
Degree of protection: IP20
-
Mounting: On DIN rail, quick and easy installation
€40.95
Items Available: 4
: 2
Abb Circuit Breaker Reliability C-Curve and Easy DIN-Rail Installation
Reliable protection with C curve
Designed to handle short-duration overcurrents up to 5-10 times the rated current, this circuit breaker provides optimal protection while avoiding unnecessary work on electrical systems.
Compact design and DIN rail installation
With a 2-DIN-module design, it is easily installed in electrical panels, taking up little space and providing convenient and safe installation.
Abb Circuit Breaker Technical Specifications
| Feature | Value |
|---|---|
| Rated current | 32 A |
| Rated voltage | 230 V AC |
| Input voltage type | AC |
| Number of poles | 1P+N |
| Number of Modules | 2 |
| Rated Frequency | 50/60 Hz |
| Curve | C |
| Power loss | 4W |
| Electrical resistance | 20000 cycles |
| Mechanical resistance | 20000 cycles |
| Overvoltage category | III |
| Tightening torque | 2.8 N-m |
| Cable stripping length | 12.5 mm |
| Ambient temperature | -25/+55 degrees |
| Degree of protection | IP20 |
| Pollution degree | 3 |
| Width | 35 mm |
| Height | 88 mm |
| Depth | 69 mm |
Rispecchia la descrizione, materiale arrivato nei tempi previsti.
Materiale conforme alla descrizione...consigliato
Data sheet
- Voltage: 230VAC
- Modules: 2
- Poles: 1P+N
- Curve: C
- Breaking capacity: 6KA
- Amps: 32A
- Circuit Protections: Circuit breakers
