Peimar Meter for Single-phase Hybrid Photovoltaic Inverters PSI-X-1PMETER-ZI


492 PSI-X-1PMETER-ZI

Peimar Meter, for Single Phase Hybrid Photovoltaic Inverters:

  • Internal current transformer (direct insertion)
  • Display with withdrawal and input data
  • Compatibility with single-phase hybrid inverters NOCTIS series
Request info about this product

Peimar Meter for Single-phase Hybrid Photovoltaic Inverters PSI-X-1PMETER-ZI

€138.36 Tax included
€138.36

Peimar Meter for Single-phase Hybrid Photovoltaic Inverters PSI-X-1PMETER-ZI

€138.36
Tax included
klarna Pay in installments with Klarna
Items Available: 9
qty

Peimar Meter for Single-phase Hybrid Photovoltaic Inverters PSI-X-1PMETER-ZI

€138.36

Buy it within and receive it from Thursday, 29 February
Two-year warranty
Secure Payment
Easy return within 14 days

Features:

  • Single-phase application
  • Rated voltage 220, 230, 240 V
  • Operating range 0.7 - 1.2 Un
  • Rated current 5A
  • Maximum current 80A
  • Frequency/Range 50, 60 / ±5 Hz
  • Power consumption 1 W
  • Max. Instantaneous consumption 5 VA
  • Brand CHINT
  • Model DDSU666
  • LCD display
  • RS485 communication
  • Operating temperature range -40°C to 60°C
  • Ambient humidity 0-95% No condensation
  • Degree of protection IP54
  • Installation method Rail mounting
  • Dimensions (H x W x D) 98 x 36 x 65 mm
  • Weight 0.2 kg
  • Compatible products Peimar single-phase hybrid inverters PSI-J (HY) NOCTIS series

Data sheet

Type:
Meters
