Mitsubishi Wi-Fi Interface MAC-597IF-E
MTS 750844
The Mitsubishi MAC-597IF-E is the next-generation Wi-Fi interface designed to provide advanced remote control of Mitsubishi Electric air conditioning systems via the MELCloud Home platform. Featuring 2.4 GHz Wi-Fi connectivity and integrated Bluetooth, this interface simplifies initial setup by eliminating the need to access an Access Point for pairing.
- Wireless connectivity: supports Wi-Fi IEEE 802.11 b/g/n at 2.4 GHz
- Easy configuration via Bluetooth (no Access Point required)
- WPA2-PSK (AES) encryption support for secure connections
- Full compatibility with MELCloud Home
- Remote control via smartphone, tablet or PC
- Compatible with Amazon Alexa and Google Home
- Exclusive use with IPv4 and DHCP (does not support static IPs)
- Wi-Fi SSID mandatory visible (does not support hidden SSIDs)
- Exclusive configuration via MELCloud Home app
- Easy installation directly on the Mitsubishi Electric indoor unit
- The wifi-interface is not compatible with pre-2009 models
This Mitsubishi Wi-Fi interface replaces the previous model MAC-587IF-E and is only compatible with the new MelCloud Home platform.
€73.32
Items Available: 106
: 96
Mitsubishi MAC-597IF-E Wi-Fi interface for MELCloud Home - with integrated Bluetooth
MELCloud Home is Mitsubishi Electric's new platform for smart control of air conditioners. Through the dedicated app, it is possible to:
- Turn the system on/off remotely
- Set temperatures, modes and timers
- Monitor consumption and system status
- Integrate with Amazon Alexa and Google Home voice assistants
- Access from multiple devices simultaneously
- Easy registration at www.melcloudhome.com
Air conditioner models compatible with the MAC-597IF-E for MelCloud Home
| Models | Compatibility |
|---|---|
| MSZ-LN**VG2*-E5/VG3*-E1 | Yes |
| MSZ-EF**VGK2* | Yes |
| MSZ-AY**VGKP2 | Yes |
| MSZ-AP**VGK2 | Yes |
| MSZ-BT**VGK2 | Yes |
| MSZ-HR**VFK2 | Yes |
| MSZ-HR/DW MFZ/MLZ / SEZ / SLZ / SFZ |
Yes |
| Mr.Slim all indoor P series | Yes |
| ATA RAC PAC | Yes |
Technical Specifications
| Parameter | Value |
|---|---|
| Input voltage | DC 12.7 V (from the internal module) |
| Power consumption | 2 W maximum |
| Dimensions (H × W × D) | 73.5 × 41.5 × 18.5 mm |
| Weight | 87 g (including cable) |
| Transmitter power level (maximum) | 20 dBm @ IEEE 802.11b |
| RF channel | 1ch ~ 13ch (2412 ~ 2472 MHz) / 0ch ~ 39ch (2402 ~ 2480 MHz) |
| Radio Protocol | IEEE 802.11b/g/n (20) |
| Encryption | AES |
| Authentication | WPA2-PSK |
| Software version | XX.00 |
| Cable length | 2,040 mm |
super simple a installé sans aucune contrainte
se refferer au mode emploi
Fast delivery very good package very communication
Tres bon produit se branche facilement sur la carte mère, et programation relativement simple
Buon servizio e prezzi onesti. Descrizione prodotti e informazioni ottime
Caro il prezzo, fa il suo lavoro e per chi vive molto fuori casa si rende utile e necessario
Article de qualité, un réel confort d’utilisation du split de climatisation à distance.
Livraison rapide, produit au top.
Bref, tout est parfait.
Produit conforme à mes attentes. Branchement par mes soins selon indications du fabricant. Très facile a faire et a mettre en service
assolutamente consigliatissimo! sia il prodotto che la spedizione da 10 e lode!
ottimo il servizio e la spedizione,davvero molto rapida.
Data sheet
- Type: Interfaces WiFi
