Abb 32A 6kA Residual Current Circuit Breaker 2P C 2 Modules

Abb
Abb
ABB DS202CRC32A300 4022903033936

Residual current circuit breaker DS202CR C32 A300 Abb with overcurrent protection with the following features:



  • Rated current: 32A
  • Rated residual current: 300 mA
  • Rated short-circuit capacity: 6 kA
  • Number of poles: 2
  • Input voltage type: AC
  • Tripping characteristic: C
  • Degree of protection: IP20
  • Number of modules: 2



2P device in two modules for protection of single-phase end-user circuits from overloads and short-circuit currents. Protection against the effects of direct alternating sinusoidal and pulsating earth fault currents. Protection against indirect contacts and additional protection against direct contacts.

Do you have questions about this product or did you not find what you were looking for? Ask us!
Abb 32A 6kA Residual Current Circuit Breaker 2P C 2 Modules
€184.27
€184.27

€184.27
Tax included
Calculate shipping cost
Out of stock
Further availability of the manufacturer
Incoming
€184.27

Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

2P device in two modules for protection of single-phase end-user circuits from overloads and short-circuit currents. Protection against the effects of direct alternating sinusoidal and pulsating ground fault currents. Protection against indirect contacts and additional protection against direct contacts.



Curve C, trip threshold from 5 to 10 times In, for application of ohmic-inductive circuits with medium inrush currents. And widely used in domestic installations.



A circuit breaker is a safety device that can automatically (i.e., without external intervention) interrupt the flow of electric current in an electrical circuit in the event of an overcurrent.



Characteristics:

  • Rated current: 32A
  • Rated residual current: 300 mA
  • Rated short-circuit capacity: 6 kA
  • Number of poles: 2
  • Input voltage type: AC
  • Tripping characteristic: C
  • Degree of protection: IP20
  • Number of modules: 2
  • Rated operating voltage: 230 V
  • Rated insulation voltage: 440 V
  • Impulse withstand voltage: 4 kV
  • Rated extreme short-circuit capacity: 10 kA
  • Maximum peak current: 0.25 kA
  • Rated frequency: 50 Hz
  • Power loss: 7.60 W
  • Energy limitation class: 3
  • Overvoltage category: III
  • Tightening torque: 4 Nm
  • Cable size: 35 mm²
  • Cable stripping length: 11 mm
  • Ambient temperature: In operation -25/+55 degrees
  • Pollution degree: 3
  • Width: 36 mm
  • Height: 86 mm
  • Depth: 72 mm

There are no reviews

Data sheet

Modules:
2
Poles:
2P
Curve:
C
Breaking capacity:
6KA
RCD Type:
AC
Differential current :
0.3A
Amps:
32A
Circuit Protections:
RCBO
