Osram electronic transformer for halogen lamps 220/12V 35/105W ETPAR105I


LDV ETPAR105I 4008321111586

Osram electronic transformer, for 200/12V 35/105W halogen lamps.

Request info about this product

Osram electronic transformer for halogen lamps 220/12V 35/105W ETPAR105I

€16.26
€16.26

Osram electronic transformer for halogen lamps 220/12V 35/105W ETPAR105I

€16.26
Tax included
klarna Pay in installments with Klarna
qty

Osram electronic transformer for halogen lamps 220/12V 35/105W ETPAR105I

€16.26

Buy it within and receive it from Thursday, 20 June
Two-year warranty
Secure Payment
Easy return within 14 days
Product Advantages
  • Downward phase-cut dimming
  • Low power loss due to high efficiency
  • Protective operation over the entire part-load range to ensure long lamp life

Application Areas:
  • Effect and accent lighting
  • Living rooms
  • Object lighting
  • Meeting rooms
  • Restaurants
  • Furniture luminaires for recessed or surface mounting
  • Store lighting
  • Event rooms

Product Features:
  • Line frequency: 50...60 Hz
  • RI suppression: in accordance with EN 55015 (A1: 2007)/CISPR 15, EN 55022
  • Line harmonics: according to EN 61000-3-2
  • Immunity: according to EN 61547
  • Safety: according to EN 61347
  • Short circuit, overload, overtemperature protection: electronically reversible
  • Electrical isolation between primary and secondary side
  • Commutation between the electronic transformer and the lamp not allowed


Technical characteristics:
  • Electrical data Lamp power 35...105 W
  • Supply current 0.45 A
  • Nominal voltage 220...240 V
  • Power factor λ 0.95
  • Operating frequency 40 kHz
  • Output voltage 11.5 V
  • Mains frequency 50...60 Hz
  • System power 111W
  • DC voltage
  • Max. no. of ECGs with 10A auto 23
  • Max. no. of ECGs w/autom. circuit 16A 38
  • Galvanic isolation primary/secondary 4.00 kV
  • Dimensions and weight Length 128.0 mm
  • Width 38.0 mm
  • Height 31.0 mm
  • Distance between fixing holes-length 119.0 mm
  • Input cable stripping 12 / 6.0 mm
  • Output cable stripping 12 / 6.0 mm
  • Product weight 130.00 grams
  • Temperature Ambient temperature 0...+40 °C
  • Operating temperature 85 °C
  • Additional Product Data Shape / Finish Compact
  • Features Dimmer Phase control front down
  • Overload protection Yes
  • Over-temperature protection Auto power off, reversible
  • Short circuit protection Reversible
  • Max system cable length 2.0 m
  • Cable type, input side H03VV-F 2x0.75 mm²
  • Cable type, output side H03VV-F 2x0.75 mm²
  • Dimmable
  • Adjustment range 0...100
  • No-load operation test Yes
  • Suitable for luminaires with front glass II

Data sheet

Type:
Electronic transformers
