Comfort and Technology with the Dual LG Libero Smart
The LG Libero Smart Wi-Fi R32 A++/A+ Air Conditioner is a highly technological unit, designed to optimize comfort and improve the energy efficiency of your home. Thanks to its advanced technology and integrated Wi-Fi, you can easily manage the temperature and operating modes directly from your smartphone. The elegant and functional design fits perfectly into any environment, ensuring superior performance with low noise.
Advantages:
- BLDC Ventilation Motor: Greater efficiency and lower noise compared to traditional motors.
- Integrated Wi-Fi: Control the air conditioner via the Smart ThinQ app on Android and iOS.
- Voice Control Compatibility: Management via Google Home for turning on, off, and adjusting the temperature.
- Total Airflow Control: Vertical adjustment in 6 steps and horizontal in 5 steps for maximum comfort.
- Comfort Air Function: Automatic positioning of the deflector based on the operating mode.
- Smart Diagnosis: Diagnose and resolve issues via smartphone with the Smart Diagnosis app.
LG Libero Smart: Advanced Design and Functionality
BLDC Ventilation Motor
The LG Libero Smart air conditioner is equipped with a BLDC (Brushless DC) ventilation motor, which ensures more efficient operation compared to traditional alternating current motors. With greater capacity modulation and a wider range of rotational speeds, this motor reduces energy consumption and heat generation, ensuring quieter operation without electrical buzzing.
Integrated Wi-Fi Control and Voice Control
Thanks to the integrated Wi-Fi, you can easily manage all the air conditioner's functions directly from your smartphone using the Smart ThinQ app available for both Android and iOS devices. Additionally, the unit is compatible with Google Home voice assistants, allowing control via voice commands. You can turn it on, off, and adjust the temperature without leaving the couch.
Total Airflow Adjustment
The LG Libero Smart Air Conditioner offers complete airflow control with the ability to adjust the deflector orientation in 6 vertical steps and 5 horizontal steps. Thanks to this feature, you can enjoy personalized comfort, optimally directing the air for each environment.
Comfort Air Function and Smart Diagnosis
With the Comfort Air Function, the unit automatically adjusts to enhance the user experience. During heating, the deflector positions lower, while in cooling, it moves upwards, ensuring even air distribution. Additionally, Smart Diagnosis allows you to diagnose and resolve any issues directly from your smartphone with the dedicated app, facilitating maintenance.
Technical Specifications of the Dual Libero Smart
Libero Smart 9000BTU Indoor Unit
| Feature |
Description |
| Nominal Cooling / Heating Capacity |
2.5 / 3.2 kW |
| Nominal Power Consumption |
18 W |
| Nominal Current Consumption |
0.16 A |
| Power Supply |
1 Ø / 220-240V / 50Hz |
| Ventilation Capacity (Max / Med / Min) |
9.2 / 7.4 / 5.6 m³/min |
| Sound Pressure Cooling (Max / Med / Min) |
36 / 33 / 27 dB(A) |
| Sound Power Cooling |
57 dB(A) |
| Dehumidification Capacity |
0.9 l/h |
| Dimensions (W x H x D) |
837 x 308 x 189 mm |
| Net Weight |
8.7 kg |
| Liquid/Gas Connection Pipe Diameter |
Ø 6.35 mm (1/4") / Ø 9.52 mm (3/8") |
Libero Smart 18000BTU Indoor Unit
| Feature |
Description |
| Nominal Cooling / Heating Capacity |
5.0 / 5.8 kW |
| Nominal Power Consumption |
39 W |
| Nominal Current Consumption |
0.28 A |
| Power Supply |
1 Ø / 220-240V / 50Hz |
| Ventilation Capacity (Max / Med / Min) |
14.2 / 11.3 / 9.9 m³/min |
| Sound Pressure Cooling (Max / Med / Min) |
44 / 38 / 35 dB(A) |
| Sound Power Cooling |
59 dB(A) |
| Dehumidification Capacity |
0.9 l/h |
| Dimensions (W x H x D) |
998 x 345 x 210 mm |
| Net Weight |
11.9 kg |
| Connection Pipe Diameter Liquid/Gas |
Ø 6.35 mm (1/4") / Ø 12.7 mm (1/2") |
Outdoor Unit 6.2kW 3 connections
| General Data |
| Power Supply (Ø,V;Hz) |
1, 220~240 V, 50 Hz |
| Colour |
Grey |
| Weight |
46.7 kg |
| Dimensions (WxHxD) |
870 × 650 × 330 mm |
| Performance |
| Cooling Capacity (Min-Nom-Max) |
6.2 kW |
| Heating Capacity (Min-Nom-Max) |
7 kW |
| Cooling Power Consumption (Min-Nom-Max) |
1.47 kW |
| Heating Power Consumption (Min-Nom-Max) |
1.56 kW |
| S.E.E.R. / S.C.O.P. |
8.75 / 4.65 |
| Energy Efficiency Class (Cool/Heat) |
A+++ / A++ |
| Sound Data |
| Sound Pressure Level in Cooling (Nom) |
47 dB(A) |
| Sound Pressure Level in Heating (Nom) |
50 dB(A) |
| Sound Power Level (Max) |
61 dB(A) |
| Components |
| Fan |
Helical with BLDC motor |
| Compressor |
Twin Rotary |
| Number of Compressors |
1 |
| Refrigerant Control |
EEV (Electronic Expansion Valve) |
| Refrigerant |
| Refrigerant Type |
R32 |
| GWP |
675 |
| t-CO2 eq |
0.94 |
| Precharged Refrigerant Quantity |
1350 g |
| Refrigerant Increment |
20 g/m |
| Connections and Installation |
| Liquid Pipe Connection |
6.35 mm (1/4") x3 |
| Gas Pipe Connection |
9.52 mm (3/8") x3 |
| Maximum Number of Connectable Indoor Units |
3 |
| Maximum Allowable Connectivity |
12 x 12 x 9 |
| Total Maximum Piping Length |
50 m |
| Maximum Single Piping Length |
25 m |
| Piping Length with Precharge |
30 m |
| Maximum Allowable Height Difference (Indoor Unit-Outdoor Unit) |
15 m |
| Minimum Single Piping Length |
3 m |
