Finder PLR OPTA analog expansion module 6IN/6OU 24V 8A269024060C
FIN 8A269024060C
8012823458496
Finder PLR OPTA analog expansion module Type 8A.26, connection via AUX port, programmable in CODESYS:
-
24V DC power supply
-
6 analog inputs (programmable up to 8)
-
6 analog outputs
-
Compatible with CODESYS development environment
-
Connection to OPTA and other modules via auxiliary AUX port
-
Operating range: 9.6…28.8 V DC
-
Ambient temperature: –20 °C / +50 °C
-
Dimensions (W×H×D): 70 × 84 × 56.8 mm
-
Compact design for electrical panels and automation
€190.40
Items Available: 1
Finder analog expansion module, flexible expansion for OPTA automation systems
The Finder PLR OPTA 8A.26 analog expansion module is designed to enhance the functionality of OPTA controllers, offering a greater number of analog inputs and outputs for industrial automation, building automation, and process control applications.
The connection is simple and quick via AUX port, allowing direct integration with the main OPTA module and additional expansion modules, without complex wiring or intricate configurations.
Inputs and outputs programmable with CODESYS
The module features 6 analog inputs, expandable and programmable up to 8, and 6 analog outputs, ensuring high flexibility in signal management. The CODESYS development environment allows for advanced and standardized programming, ideal for professional applications requiring precision, reliability, and scalability.
Thanks to native compatibility with CODESYS, the module easily integrates into modern control architectures, reducing development and commissioning times.
Reliability and compactness for electrical panels
Designed to operate over a wide voltage range (9.6…28.8 V DC) and with an ambient temperature between –20 °C and +50 °C, the 8A.26 module is suitable for installations in industrial and technical environments. The compact dimensions (70 × 84 × 56.8 mm) allow installation in electrical panels even with limited space, maintaining order and accessibility.
| POWER SUPPLY | |
|---|---|
| Nominal supply voltage | 24 V |
| Type of supply | DC |
| DC operating range | 9.6 … 28.8 V |
| INPUTS / OUTPUTS | |
| Number of inputs | 6 (programmable up to 8) |
| Number of outputs | 6 |
| SOFTWARE | |
| Programming languages | Codesys |
| Version | Codesys |
| TEMPERATURES | |
| Operating ambient temperature | -20 °C … +50 °C |
| DIMENSIONS | |
| Dimensions (W × H × D) | 70 × 84 × 56.8 mm |
There are no reviews
Data sheet
- Type: OPTA Logic Relays
- Voltage: 24V
