FG16OR16 Double Insulated Flameproof Cable 3x35 + 1x25 sq. mm 0.6/1 kV

Cavi
9X9 FG16R4X35

FG16OR16 Double Insulated Flameproof Cable 3x35 + 1x25 sq mm with the following characteristics:



  • Conductor diameter: 7.6 mm
  • Insulation thickness: 0.9 mm
  • Sheath thickness: 1.8 mm
  • Production diameter: 29.2 mm
  • Max electrical resistance at 20°C: 0.554 ohm/ km
  • Current carrying capacity in air pipe: 128A
  • Current carrying capacity in buried pipe: 114A



Sold per meter.

The producers of our cables are:

  • Baldassari cavi
  • Icel
  • La Triveneta
  • Prysmian
The delivery of the cable from one manufacturer rather than another is dictated by the availability of the moment. All our cables comply with the relevant legal regulations.
The right of withdrawal does not apply to this product as the cables are cut according to your personal specifications.
Depending on the length and/or diameter of the cable, transport may require the use of reels. This option involves an additional cost, which will be communicated upon completion of the order according to specific requirements.
Do you have questions about this product or did you not find what you were looking for? Ask us!
FG16OR16 Double Insulated Flameproof Cable 3x35 + 1x25 sq. mm 0.6/1 kV
€21.56
€21.56

€21.56
Tax included
Calculate shipping cost
Items Available: 6411
Further availability of the manufacturer
€21.56

Buy it within and receive it from Monday, 22 December
Two-year warranty
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Multi-core energy cable insulated with high-modulus ethylene-propylene rubber of G16 quality, under PVC sheath, with special fire reaction characteristics and complying with the Construction Products Regulation (CPR).




Features:

  • Conductor: Flexible annealed red copper cord, class 5
  • Insulation: High-modulus ethylpropylene rubber compound of G16 quality
  • Filler: Compound of non-hygroscopic material
  • Outer sheath: PVC compound of quality R16
  • Rated voltage Uo/U: 0.6/1 kV
  • Maximum operating temperature: 90°C
  • Minimum operating temperature: -15°C (in the absence of mechanical stress)
  • Minimum installation temperature: 0°C
  • Maximum short-circuit temperature: 250°C up to 240 mm² section, over 220°C
  • Maximum tensile stress: 50 N/mm2
  • Minimum bending radius: 4 times the maximum outer diameter




Conditions of use: Cables suitable for power supply in buildings and other civil engineering works with the aim of limiting the production and spread of fire and smoke. For use indoors in even wet rooms or outdoors (AD7). Suitable for fixed installation on masonry and metal structures in free air, in pipe or duct or similar systems. Also permitted for underground installation. Good resistance to industrial oils and greases (ref. IEC 20-67).

There are no reviews

Data sheet

Colour:
Grey
Cross-Section:
25mmq
35mmq
With yellow/green:
No
Number of cables:
4
