Vortice SCRR5 Control Box for 5-Speed Ceiling Fans 0000012963
VOR 0000012963
8010300129631
Vortice control unit for ceiling fans, 5-speed regulation. Wall installation, convertible to recessed with optional kit, with the following features:
-
Compatible: Vortice ceiling fans, with or without light
-
Speeds: 5 selectable + reverse direction function
-
Installation: Wall, with possibility of recessed installation (optional kit SCBRR5/5L/M)
-
Supply voltage: 220-240V
-
Maximum allowable load: 100 W
-
Color: White
-
Control: On/Off integrated
€35.44
Items Available: 78
: 36
Vortice control unit: complete control of your ceiling fan
This Vortice speed controller is the ideal solution for managing ceiling fans with and without lights. It offers the ability to select up to 5 speeds, optimizing comfort in any season, and allows you to reverse the direction of fan rotation to adapt to both summer and winter modes.
With its compact structure and minimal design, it can be installed on the wall easily and unobtrusively. With the special SCBRR5/5L/M kit (optional), it can be transformed into a built-in version, integrating it perfectly into any environment.
Safety and quality guaranteed
The device is designed according to Vortice safety standards, with double insulation and protection against misuse (use by children or unsupervised persons is prohibited). It is suitable for electrical systems complying with current regulations and must be installed by qualified personnel.
Recommended Applications.
-
Residential or commercial ceiling fans
-
Ventilation control in offices, meeting rooms, bedrooms, living rooms
-
Energy-saving and natural air exchange solutions
Technical Specifications Vortice Control Box
Electrical Specifications
| Supply voltage | 220-240V / 50 Hz |
| Max power consumption | 100 W |
Installation and Structure
| Installation type | Wall-mounted / recessed (optional) |
| Built-in kit (optional) | SCBRR5/5L/M |
| Weight | 0.6 kg |
| Color | White |
Functions and Compatibility
| Selectable speeds | 5 |
| Reverse function | Yes |
| Compatibility | Vortice fans |
There are no reviews
Data sheet
- Type: Speed controllers
