Abb Modular Disconnect Switch E 91N/32 2P 32A IP20 M200893
ABB M200893
8012542008941
Abb E 91N/32 modular disconnector with the following characteristics:
- Rated AC operating current: 32A
- Rated insulation voltage (Ui): 1 kV
- Power loss: at Rated Operating Conditions per pole 3 W
- Number of poles protected: 1
- Number of poles: 2
- Tightening torque: 2 to 2.5 Nm
- Degree of protection: IP20
€10.88
Items Available: 44
: 18
Features:
- Rated operating voltage: AC-20B 690 V|AC-22B 400 V
- Rated frequency: 50/60 Hz
- Lock type: padlock when open
- Mounting type: of rail
- Gasket Type: Sealing wire
- Conductor Material: Copper
- Recommended screwdriver: Pozidrive 2
- Shock and vibration resistance acc. to IEC 61373:Category 1, Class B
- Connection capacity: Rigid 2x5 mm²
- Operating humidity (RH amb ):max. 90% at temp. +20°C 50% at max. temp. +40°C
- Ambient temperature: In operation -5...+40 °C - In storage -25...+70 °C
There are no reviews
Data sheet
- Voltage: 690V
- Poles: 2P
- Amps: 32A
- Circuit Protections: Disconnectors
- Operating voltage: AC
