Dichroic Led Bulb MR16 Ledvance Osram 3.4W GU5.3 base 2700K
LDV PM1635D927362
4099854456572
LED bulb dichroic Ledvance Osram MR16 35 36° DIM P, ideal for accent lighting:
-
GU5.3 base, operation 12 V AC/DC
-
Light beam 36 degrees for accent lighting
-
Power 3.4 Watt (halogen equivalent 35 Watt)
-
Dimmable to adjust light intensity
-
Warm white light 2700 Kelvin, with CRI > 90
-
High compatibility with dimmers
-
Luminous flux: 345 lm
-
Lifetime up to 25,000 hours
-
Frequency: 50/60 Hz
-
Energy class: E
€7.25
Items Available: 7
: 4
Dichroic Bulb MR16 35 Ledvance, LED alternative to low voltage halogens
The Ledvance Osram MR16 35 36° DIM dichroic LED bulb is a valid LED alternative to traditional low voltage halogen lamps. Thanks to the reduced consumption of only 3.4 W, it effectively replaces a 35 W lamp, ensuring significant energy savings without compromising on light quality.
The compact design, standard dimensions, and luminous flux comparable to halogens make replacement quick, simple, and safe, without the need to rewire the system.
Light quality and intensity control
The 2700 Kelvin colour temperature (warm white) and high colour rendering index Ra 90 ensure a natural perception of colours, ideal for environments where light quality is essential. The concentrated 36° beam makes this bulb perfect for accent lighting, showcases, exhibitions, and decorative light points.
The dimmable function allows continuous adjustment of light intensity, with instant 100% ignition and no warm-up time. The high compatibility with most common electronic and conventional dimmers ensures great flexibility of use.
Reliability and long lifespan
It is suitable for domestic, commercial, and retail applications, as well as for outdoor use exclusively in suitable lighting fixtures.
| ELECTRICAL DATA | |
|---|---|
| Nominal power | 3.4 W |
| Nominal voltage | 12 V |
| Operating mode | 12 V AC / DC |
| Conventional lamp equivalence | 35 W |
| Base | GU5.3 |
| Nominal current | 320 mA |
| Current type | AC / DC |
| Inrush current | 0.32 A |
| Mains frequency | 50/60 Hz |
| Max number of lamps on MCB B10 | 29 |
| Max number of lamps on MCB B16 | 56 |
| Total harmonic distortion | 150 % |
| Power factor (λ) | > 0.50 |
| Mercury content | 0.0 mg (mercury-free) |
| PHOTOMETRIC DATA | |
| Luminous flux | 345 lm |
| Nominal useful luminous flux (90°) | 345 lm |
| Luminous intensity | 800 cd |
| Luminous efficacy | 101 lm/W |
| Light colour | Warm white |
| Colour temperature | 2700 K |
| Colour rendering index (CRI) | Ra 90 |
| Colour code | 927 |
| Standard colour deviation | ≤ 5 SDCM |
| Flicker (Pst LM) | ≤ 1.0 |
| Stroboscopic effect (SVM) | ≤ 0.4 |
| LIGHTING SPECIFICATIONS | |
| Beam angle | 36° |
| Warm-up time (60%) | < 0.5 s |
| Start-up time | < 0.5 s |
| Dimmable | No |
| DIMENSIONS AND WEIGHT | |
| Total length | 44 mm |
| Diameter | 50 mm |
| Product weight | 36 g |
| TEMPERATURES AND OPERATING CONDITIONS | |
| Ambient temperature | -20…+40 °C |
| Maximum tc point temperature | 85 °C |
| Storage temperature | -20…+80 °C |
| LIFESPAN | |
| Lifespan L70/B50 @ 25 °C | 25,000 h |
| Number of switching cycles | 100,000 |
| Luminous flux maintenance at end of life | 0.96 |
| CERTIFICATIONS AND STANDARDS | |
| Energy efficiency class | E |
| Energy consumption | 4.00 kWh / 1000 h |
| Protection grade | IP20 |
| Standard | CE, EAC, UKCA |
| Photobiological risk group (EN 62778) | RG1 |
There are no reviews
Data sheet
- Type: LED
- Connection: GU5.3
- Staining: Warm
- Shape: Spotlight
- Energy class: E
- Dimmable: Yes
- Colour temperatures: 2700 Kelvin
