The device allows the shutter/blind to be controlled via buttons connected to the P and P inputs and via a wireless connection. The device has the possibility to be controlled with two different radio standards (exclusive of each other): Bluetooth mesh (default) or Zigbee (settable via View Wireless app). The Bluetooth mesh network implies the presence of the 20597 - 19597 - 14597 gateway while the dialogue via ZIGBEE requires a Zigbee gateway (e.g. Alexa Echo Plus or Echo Show).

Equipped with an output with 2 monostable relays with interlocked operation, that is with mutually exclusive activation of the relays with minimum interlocking time. In the absence of power from the relays both relays remain open.

The buttons connected to the device inputs command only the rolling shutter actuator on board:

• short press: if the shutter is stationary the slat rotates; if the shutter is moving it stops;
• long press: the upper key raises the shutter while the lower key lowers it;
• press both buttons: recall the preferred position (storage is via the View Wireless app).



Features:

• Rated supply voltage: 100-240 V~, 50/60 Hz
• Power dissipation: 0.55 W
• Transmitted RF power: < 100mW (20 dBm)
• Frequency range: 2400-2483.5 MHz
• Terminals: 2 terminals (L and N) for line and neutral - 2 terminals (? and ?) for the shutter output - 2 terminals (P? and P?) for connecting the buttons to control the actuator and for configuration. For the control of the actuator use buttons art. 20066-19066-16121- 14066 or art. 20062-19062-16150-14062 while for the configuration use only buttons art. 20066-19066-16121-14066
• RGB LED indicating the configuration status (flashing blue)
• In Bluetooth technology mode, up to 2 radio devices (art. 03925) can be associated with the device, allowing the control of the actuator or the activation of a scenario.
