Bticino Circuit Breaker 40A 4 Poles 16KA Curve D 6 Modules FT84D40
BTI FT84D40
8005543702598
Bticino thermal-magnetic circuit breaker:
- Power In 40A
- 4 Poles
- Breaking capacity Icu 16KA
- Tripping curve D
- 6 Modules
€303.79
Items Available: 1
Curve D, trip threshold of 10 to 20 times In, for application of circuits with high inrush currents (motors, transformers, etc.).
A circuit breaker is a safety device that can automatically (i.e., without external intervention) interrupt the flow of electric current in an electrical circuit in the event of an overcurrent.
Characteristics:
- Reference Standard IEC EN 60947-2
- Voltage 400 Vac
- Degree of protection IP20
- Height 83mm
- Width 71.2mm
- Depth 76mm
- Maximum cable cross section 25/35mmq
There are no reviews
Data sheet
- Voltage: 400VAC
- Modules: 6
- Poles: 4P
- Curve: D
- Breaking capacity: 16KA
- Degree of protection: IP20
- Amps: 40A
- Circuit Protections: Circuit breakers
