Chint Circuit Breaker NXB-63S 4P 50A 4.5kA C 4M 296910

Chint
Chint
CHT 296910 6925808315917

Circuit breaker NXB-63S, reliable protection for three-phase circuits, with the following features:

  • Number of Poles: 4P

  • Rated current: 50 A

  • Tripping curve: C

  • Rated voltage: 400 Vac, frequency 50/60 Hz

  • Interrupting capacity: 4.5 kA

  • Number of Modules: 4

  • Degree of protection: IP20

Do you have questions about this product or did you not find what you were looking for? Ask us!
Chint Circuit Breaker NXB-63S 4P 50A 4.5kA C 4M 296910
€23.20
€23.20

€23.20
Tax included
Calculate shipping cost
Out of stock
Further availability of the manufacturer
Incoming
€23.20

Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Frequently bought together

Chint circuit breaker comprehensive protection for three-phase systems

The NXB-63S/C20-4P-4.5 circuit breaker offers safe and effective protection against overloads and short circuits in three-phase electrical systems. Due to the tripping curve C, it is suitable for loads with moderate inrush currents, such as motors, switchgear and machinery.

The C curve can tolerate short-duration overcurrents up to five to ten times the rated current and is widely used in domestic systems.

High performance in compact size

This 4-pole, 50 A device operates with a voltage of 400 V and a frequency of 50/60 Hz, ensuring reliability in industrial and tertiary settings. With 4 DIN modules and IP20 degree of protection, it easily integrates into any standard electrical panel.

Certified safety and reliability

The breaking capacity of 4.5 kA, limitation class 3 and impulse voltage of 4 kV make this circuit breaker suitable for protection even in the presence of voltage spikes. Low power dissipation (4.5 W) enables efficient and safe operation.

Compatible with signaling and protection accessories

It can be accessorized with:

  • AX-X1 auxiliary contacts

  • AL-X1 alarm contacts

  • SHT-X1 trip coils

  • Minimum voltage coils UVT-X1

Not compatible with differential modules

Technical Characteristics Circuit Breaker Chint

Number of poles 4P
Rated current (In) 50 A
Tripping curve C
Rated voltage (Vn) 400 Vac
Frequency 50/60 Hz
Impulse voltage (Uimp) 4 kV
Interrupting capacity (Icn) 4.5 kA
Limitation class 3
Power dissipation 3W
Number of DIN modules 4
Degree of protection IP20
Dimensions (h × w × d) 81 × 72 × 78 mm
Compatible accessories AX-X1, AL-X1, SHT-X1, UVT-X1

There are no reviews

Data sheet

Voltage:
400VAC
Modules:
4
Poles:
4P
Curve:
C
Breaking capacity:
4.5KA
Degree of protection:
IP20
Amps:
50A
Circuit Protections:
Circuit breakers
