Chint Circuit Breaker NXB-63S 4P 25A 4.5 kA Curve C 4M 296907

Chint
Chint
CHT 296907 6941716449087

Circuit breaker Chint NXB-63S, reliable protection for three-phase systems, with the following characteristics:

  • Number of poles: 4P

  • Rated current: 25 A

  • Intervention curve: C

  • Rated voltage: 400 Vac

  • Breaking capacity: 4.5 kA

  • Impulse voltage: 4 kV

  • Number of modules: 4

  • Protection degree: IP20

Do you have questions about this product or did you not find what you were looking for? Ask us!
Chint Circuit Breaker NXB-63S 4P 25A 4.5 kA Curve C 4M 296907
€18.29
€18.29

€18.29
Tax included
Calculate shipping cost
Items Available: 2
Further availability of the manufacturer
€18.29

Buy it within and receive it from Wednesday, 24 December
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Circuit breaker Chint effective protection for three-phase circuits

The NXB-63S/C25-4P-4.5 circuit breaker is a protection device designed to automatically interrupt the electrical circuit in case of overloads or short circuits, contributing to the safety and operational continuity of the system. Thanks to the 4 poles, it is ideal for three-phase systems with neutral and finds application in both residential and tertiary environments.

Certified reliability according to IEC standards

Manufactured in compliance with IEC/EN 60898-1 standard, this circuit breaker ensures a breaking capacity of 4.5 kA, suitable for protecting terminal distribution in small and medium-sized installations. The limitation class 3 guarantees a high capacity to reduce passing energy, minimizing damage in case of failure.

Intervention curve C balance between sensitivity and selectivity

The circuit breaker is characterized by a curve C, which allows intervention in the presence of overcurrents from 5 to 10 times the nominal current (25 A). This feature makes it ideal for:

  • Domestic installations

  • Secondary distribution boards

  • Applications with moderately inductive loads (small motors, transformers, etc.)

Quick installation and integration in DIN boards

Thanks to the 4-module format and compact dimensions, the circuit breaker fits perfectly into standard modular electrical panels. The IP20 protection degree ensures good safety against direct contact, making the device suitable for mounting inside protected panels.

Compatibility with functional accessories

The device can be equipped with:

  • Auxiliary contacts series AX-X1

  • Alarm contacts series AL-X1

  • Shunt trip coils series SHT-X1

  • Undervoltage coils series UVT-X1

Not compatible with differential modules, therefore for differential protection it is necessary to use external or dedicated devices.

Recommended applications

Thanks to its configuration and technical characteristics, the NXB-63S/C25-4P circuit breaker is suitable for:

  • Three-phase distribution boards

  • Civil and commercial installations

  • Protection of mixed loads (lighting, sockets, small motors)

  • Systems requiring integration with remote trippers

Technical Characteristics Chint Circuit Breaker

Number of poles 4P
Rated current (In) 25 A
Intervention curve C
Rated voltage (Vn) 400 Vac
Frequency 50 / 60 Hz
Breaking capacity (Icn) 4.5 kA
Impulse voltage (Uimp) 4 kV
Limitation class 3
Dissipated power 4.5 W
Number of DIN modules 4 (72 mm)
Protection degree IP20
Dimensions (H × W × D) 81 × 72 × 78 mm

There are no reviews

Data sheet

Voltage:
400VAC
Modules:
4
Poles:
4P
Curve:
C
Breaking capacity:
4.5KA
Degree of protection:
IP20
Amps:
25A
Circuit Protections:
Circuit breakers
