Product advantages:

• Indoor luminaire with high luminous efficiency
• Energy savings of up to 55 % compared to luminaires using CFLs
• Quick and easy installation
• Extremely uniform light



Applications:

• Corridors
• Stairways
• Bathrooms
• Halls



Construction features:

• Type of protection: IP44 (ceiling mount), IP20 (wall mount)
• Impact resistance: IK03
• Aluminum housing and PMMA cover
• Ambient temperature during operation: -20 to 40 °C
• Indoor use only, not suitable for outdoor use



Features:

• Rated voltage 220/240 V
• Mains frequency 5060 Hz
• Rated current 140 mA
• Trigger current 7 A
• Limit.inrush current Th50 212 µs
• Num. Max. of lum. on switch B16 A 35
• Num. Max. of lum. on switch C10 A 35
• Max. no. of luminaires per circuit breaker C16 56
• Power factor ? > 0,55
• Total harmonic distortion < 120 %
• Safety class I
• Mode of operation Integrated LED driver



Photometric Data:

• Luminous flux 1440 lm
• Luminous efficiency 80 lm/W
• Color temperature 3000 K
• Light color (description) Warm white
• Color Rendering Index Ra > 80
• Standard Deviation of Color Matching < 6 sdcm
• Photobiological Safety Group EN62778 RG0
• Photobiological safety group EN62471 RG0
• Beam width 120 degrees



Materials and colors:

• Product color White
• Body color White
• Body Material Steel
• Cover Material Polymethylmethacrylate (PMMA)
• Light-emitting surface material PMMA
• Glow wire test (IEC 60695-2-12) 650 °C
• Mercury content in the lamp 0.0 mg



Applications and installation:

• Ambient temperature -20+40 °C
• Storage temperature -20+80 °C
• Connection type Terminal, 3-pin
• Degree of protection IP44 (Type of protection: IP44 (ceiling mount), IP20 (wall mount)
• IK index (shock resistance)
• PIM IK03
• Surface type mounting
• Mounting location Ceiling, Wall
