Ajax Smart Wireless Socket Socket Type F Jeweller White
08T 38209
4823114015793
Ajax Jeweller Smart Socket F-type offers wireless control, energy monitoring and advanced automation scenarios, enabling energy management via smartphone and optimizing consumption.
-
Real-time monitoring of energy consumption
-
Remote control via Ajax app
-
Automation scenarios for on/off, temperature, humidity and CO2
-
Compatible with LifeQuality Jeweller for environmental monitoring
-
Hourly scheduling and activation via LightSwitch or Button
-
Compact design and easy installation
€102.61
Items Available: 29
Smart Socket: Intelligent energy monitoring and management
The Ajax Socket F-type Jeweller smart socket is an advanced device that allows users to monitor the energy consumption of connected devices in real time. Through the Ajax app, users can view a detailed log of events and make informed decisions to optimize energy use. This feature helps not only to reduce consumption but also to prevent overloads and damage to electrical devices, making the home or work environment more efficient.
Remote control and automation scenarios
The device connects to a 230 V AC source and closes the circuit on command. The smart socket can handle loads up to 2.5 kW, enough to connect devices with high energy consumption.
With Ajax Socket, users have full control of their devices remotely, directly from their smartphones. In addition to manual management via app, the socket supports customizable automation scenarios. Turns on and off can be programmed based on time of day, temperature, humidity, or CO2 concentration in the environment, thanks to integration with devices such as LifeQuality Jeweller. For example, the outlet can be configured to turn on when the temperature drops below a certain value or turn off when the humidity exceeds a predefined threshold.
When you leave the house, close the door and turn the system on. All major appliances that consume energy and are dangerous will be automatically turned off. Iron, stove and toaster will no longer risk generating a fire.
Advanced automation for comfort and safety
Ajax Socket is not limited to being a simple smart socket, but becomes an integrated automation center. With the ability to configure activation scenarios via the LightSwitch or Button, the device can perform predefined actions to meet specific needs. For example, a heater or fan can be activated automatically based on changes in temperature or humidity, or react to alarms for proactive security management.
Design and ease of use
The Ajax Socket type F Jeweller features a sleek and compact design that is easy to install in any environment. It is compatible with most standard electrical appliances and integrates easily into your existing Ajax automation system. With its wireless connection and easy configuration via the Ajax app, it is perfect for those looking for an intuitive and powerful smart home solution.
Consumption under control
Socket communicates which devices consume the most energy. As soon as an appliance starts consuming electricity, Socket's LED changes color in real time.
Socket complies with standards for electrical appliances and ensures your safety. Each smart socket is tested to ensure the quality of materials, the effect of high temperatures, and the ability to operate under load for long periods of time.
Special shutters inside Socket protect children and prevent them from inserting screwdrivers, pencils and nails. They also protect against dust and splashes.
Ajax Socket Specifications
Compatibility with Ajax devices
| Feature | Value |
|---|---|
| Compatibility with Ajax devices |
|
Power supply
| Feature | Value |
|---|---|
| Supply voltage | 110-230 V~, 50/60 Hz |
| Maximum continuous load current | 11 A |
| Output power | Up to 2.5 kW (resistive load at 230 V~), Up to 1.2 kW (resistive load at 110 V~) |
| Average consumption | Up to 1 W |
| Overcurrent Protection | More than 11 A (when Current Protection is on), More than 13 A (when Current Protection is off) |
| Overvoltage protection for 230 V~ power grid. | Min: 184 V~, Max: 253 V~ (socket will automatically turn off when voltage exceeds specified levels) |
| Overvoltage protection for 110 V~ power grid. | Min: 88 V~, Max: 121 V~ (socket automatically shuts off when voltage exceeds specified levels) |
| Protection against overheating | More than +85 °C (the socket will turn off if the protection is activated) |
| Protection class against electric shock | Class I (with grounding terminal) |
Jeweller communication technology
| Feature | Value |
|---|---|
| Technology | Proprietary wireless for transmission of commands, alarms and events |
| Two-way communication | Yes |
| Advanced anti-sabotage system | Yes |
| Block encryption with mobile key | Yes |
| Instant notifications | Yes |
| Remote control and configuration in Ajax apps | Yes |
| Operating frequencies | 866.0-866.5 MHz, 868.0-868.6 MHz, 868.7-869.2 MHz, 905.0-926.5 MHz, 915.85-926.5 MHz, 921.0-922.0 MHz |
| Maximum effective radiated power (ERP) | Up to 25 mW |
| Radio signal modulation | GFSK |
| Radio communication range | Up to 1,000 m (between device and hub or repeater in open field) |
| Encrypted communication | All saved and transmitted data are protected by block encryption with a moving key |
| Frequency hopping | To avoid radio interference and signal inhibition |
Key Features
| Feature | Value |
|---|---|
| Control via smartphone | User can set smart socket configurations and receive a detailed event log in the Ajax app |
| Automation scenarios | For on/off, scheduling, alarm, temperature, humidity, CO₂ concentration (available with LifeQuality Jeweller) |
| Energy consumption monitoring | Monitoring of current, voltage, power consumption and power consumed by connected appliances |
| Adjustable pulse duration | From 1 to 255 s |
| LED indication | Informs about socket status and energy consumption, brightness adjustable or off in Ajax app |
| Modes of operation | Pulse-controlled, bistable |
| Contact status | Normally open, normally closed |
| Safe for children | Internal safety shutters to protect children from foreign objects and from dust and splashes |
Anti-sabotage protection
| Feature | Value |
|---|---|
| Protection against counterfeiting | Device authentication |
| Detection of connection loss | Within 36 s (depends on Jeweller or Jeweller/Fiber settings) |
Case
| Feature | Value |
|---|---|
| Dimensions | 45 × 45 × 65.5 mm |
| Weight | 58 g |
| Operating Temperatures | 0 °C to +40 °C |
| Maximum allowable humidity | Up to 75% without condensation |
| Protection class | IP55 |
Material in the package
| Feature | Value |
|---|---|
| Button Jeweller | Yes |
| CR2032 battery (pre-installed) | Yes |
| Quick Start Guide | Yes |
In questi anni ne ho già installate 2 e funzionano come da specifiche del fornitore
Ė un prodotto che sto provando per la prima volta, per ora tutto ok
Data sheet
- Colour: White
- Type: Wireless Sockets
- System: Wireless
